Christian Petrie

The Advanced Fuels Campaign within the Fuel Cycle Research and Development program of the Department of Energy (DOE) Office of Nuclear Energy is currently investigating a number of advanced nuclear fuel cladding concepts to improve the accident tolerance of light water reactors (LWRs). Some of the leading candidates to replace traditional zirconium-based cladding are aluminaforming ferritic alloys (e.g., FeCrAl) and silicon carbide (SiC) composites. Oak Ridge National Laboratory has developed experimental designs to irradiate thin-walled cladding tubes with representative geometry in the High Flux Isotope Reactor (HFIR) under relevant LWR temperatures and in some cases under prototypic heat flux. These designs allow for post-irradiation examination (PIE) of cladding which closely resembles expected commercially viable geometries and microstructures. PIE will include studies of dimensional change, microstructure variation, mechanical performance, etc. The experiments were designed using relatively inexpensive rabbit capsules for the irradiation vehicle. The simplistic designs combined with the extremely high neutron flux in the HFIR allow for rapid testing of a large test matrix, thus reducing the time and cost for moving advanced cladding materials closer to commercialization. This work describes the capsule designs that have been developed at ORNL, some initial results, and plans for future irradiations.

Tristructural-isotropic (TRISO)–coated particle fuel is a promising advanced fuel concept being considered for several advanced reactor applications and for accident-tolerant fuel for light water reactors. One of the aspects studied in the development of this advanced fuel concept is the release of specific fission products (Ag, Eu, and Sr). The silicon carbide (SiC) layer of TRISO fuel serves as the primary barrier to metallic fission products and actinides not retained in the fuel kernel. The goal of this project is to evaluate the effect of irradiation on the diffusion of these fission products in the SiC layer of the fuel. For this purpose, rabbit capsules containing small slab diffusion couple specimens have been assembled to be irradiated in the High Flux Isotope Reactor (HFIR). The diffusion couple specimens have been fabricated using similar processes and equipment as those used to make TRISO particles; the desired fission products have been implanted in the specimens using an ion accelerator. Moreover, the effect of temperature on the fission products diffusion will be studied separately by performing thermal experiments in the absence of irradiation. This report describes the irradiation experiment design concept, summarizes the irradiation test matrix, and reports on the successful assembly of two rabbit capsules that will be irradiated in the HFIR.

This document outlines the irradiation of silicon carbide cladding tube specimens in the High Flux Isotope Reactor at Oak Ridge National Laboratory. The cladding tube specimens consisted of monolithic, composite, and coated SiC specimens in order to test the effect of these various materials on the overall cladding performance during irradiation. A total of 18 specimens were irradiated for one cycle, with 9 specimens irradiated at low heat flux conditions and 9 specimens at high heat flux conditions. The specimens were inserted in cycle 475 in September 2017 and reached an average irradiation dose of approximately 2.6 dpa.

This report provides a summary of the irradiation vehicle design and thermal analysis of absorber material specimens planned for irradiation in the flux trap of the High Flux Isotope Reactor (HFIR). Four different absorber materials will be inserted in the same capsule: hafnium carbide without additive (HfC), hafnium carbide with molybdenum silicide additive (HfC + MoSi2), samarium hafnate (Sm2HfO5), and europium hafnate (Eu2HfO5). The capsule design, with target temperatures of 300°C, will accommodate twelve specimens. Two capsules are planned to be built and irradiated to two different neutron fluence levels

This report provides a summary of the irradiation vehicle design and thermal analysis of SiC joint specimens planned for irradiation in the flux trap of the High Flux Isotope Reactor (HFIR). Two different capsule designs will be used to accommodate the two different specimen geometries: a small torsion joint specimen geometry to measure mechanical and thermal properties, and joint end plug representative cladding geometry to demonstrate strength and integrity. The capsule designs, with target temperatures of 350°C ± 50°C and 750°C ± 50°C, will accommodate either sixteen torsion joint specimens or one joint end plug specimen. Three joint variations will be studied in each capsule design: a hybrid SiC (preceramic polymer with chemical vapor deposition (CVD) SiC), a transient eutectic phase (TEP) process, and an oxide process.

The initial results of a post-irradiation examination study conducted on CVD SiC tubular specimens irradiated under a high radial heat flux are presented herein. The elastic moduli were found to decrease more than that estimated based on previous studies. The significant decreases in modulus are attributed to the cracks present in the specimens. The stresses in the specimens, calculated through finite element analyses, were found to be greater than the expected strength of irradiated specimens, indicating that the irradiation-induced stresses caused these cracks. The optical microscopy images and predicted stress distributions indicate that the cracks initiated at the inner surface and propagated outward.

The purpose of this work is to design an irradiation vehicle for testing silicon carbide (SiC) fiber-reinforced SiC matrix composite cladding materials under conditions representative of a light water reactor in order to validate thermo-mechanical models of stress states in these materials due to irradiation swelling and differential thermal expansion. The design allows for a constant tube outer surface temperature in the range of 300–350 °C under a representative high heat flux (~0.66 MW/m2) during one cycle of irradiation in an un-instrumented “rabbit” capsule in the High Flux Isotope Reactor. An engineered aluminum foil was developed to absorb the expansion of the cladding tubes, due to irradiation swelling, without changing the thermal resistance of the gap between the cladding and irradiation capsule. Finite-element analyses of the capsule were performed, and the models used to calculate thermal contact resistance were validated by out-of-pile testing and post-irradiation examination of the foils and passive SiC thermometry. Six irradiated cladding tubes (both monoliths and composites) were irradiated and subsequently disassembled in a hot cell. The calculated temperatures of passive SiC thermometry inside the capsules showed good agreement with temperatures measured post-irradiation, with two calculated temperatures falling within 10 °C of experimental measurements. The success of this design could lead to new opportunities for irradiation applications with materials that suffer from irradiation swelling, creep, or other dimensional changes that can affect the specimen temperature during irradiation.

Optical fibers provide a variety of options for instrumentation in reactor environments. Multiple physical phenomena can be measured using optical fibers including, temperature, strain, pressure, and fluid level. Optical fibers are advantageous because they are immune to electromagnetic interference, have a small diameter (~125 µm), and have a fast response. This work investigates temperature sensing with sapphire optical fiber in the Ohio State University Research Reactor (OSURR). Specifically, this work investigates temperature sensing, using the Optical Frequency Domain Reflectometry (OFDR) sensing technique. A Luna Innovations Optical Backscatter Reflectometer (OBR) 4600, was used with sapphire optical fibers with an internal cladding and that were inscribed with type-II fiber Bragg gratings (FBGs). The sapphire fiber optic temperature sensors were irradiated in the central irradiation facility (CIF) of the OSURR for five days and received a total fluence of approximately 2.5x1018 n/cm2 and a gamma dose of approximately 3.48 Grad. The temperature was uncontrolled and the maximum temperature of the air in the CIF reached approximately 80 ºC, as measured by a k-type thermocouple. Further development and characterization of the cladding process will enable the deployment of nearsingle mode sapphire optical fiber as high temperature radiation resistant sensors.

Westinghouse is developing an In-Rod Sensor (IRS) System [1, 2] capable of measuring critical fuel rod parameters such as center-line fuel temperature, rod internal pressure and axial fuel pellet stack elongation without having penetrations to the fuel rod. The technology is similar to the Halden Reactor instrumentation [3], but the IRS system focuses on commercial fuel rod instrumentation. Both systems circumvent fuel rod penetrations, however the IRS system overcomes unique geometric challenges found in commercial fuel rod assemblies. The IRS could also play a key role in accelerated fuel qualification by allowing real-time measurements during separate effects tests, integral fuel testing or during irradiation of lead test rods or lead test assemblies. Combining these measurements with data acquired from targeted separate effects testing and multi-scale modelling could significantly reduce the time required to qualify new fuel and reduce the safety margin uncertainty of operating plants. The IRS is actively in development for Light Water Reactors (LWR) based fuel assemblies but can also be applied to Gen IV reactor designs with minimal modifications.

Westinghouse Electric Company is developing wireless sensors to monitor the centerline temperature and internal pressure of commercial light-water reactor fuel rods during irradiation. Oak Ridge National Laboratory and Westinghouse Electric Company developed the Wireless Instrumented RB Experiment 2021 (WIRE-21) to test wireless temperature and pressure sensor technologies in a removable beryllium position in the High Flux Isotope Reactor. The experiment was irradiated for a total of 75 days, at temperatures ranging from approximately 150°C to 400°C, resulting in a peak fast (energy > 0.1 MeV) neutron fluence of about 3 × 1021 n/cm2. The temperature was intentionally cycled multiple times to compare the response of the wireless temperature sensor to collocated thermocouples. Similarly, the pressure sensor was actuated in multiple steps to compare the response of the wireless measurement to excore pressure transducers (Petrie et al., 2023). After irradiation, the experiment was disassembled in the Irradiated Fuels Examination Laboratory (IFEL) hot cell at Oak Ridge National Laboratory with the intent to recover sensor and dosimetry components, document the as-irradiated condition of the hardware, and investigate possible causes of the sensor behavior observed during irradiation. The postirradiation examination successfully recovered and preserved key WIRE-21 components. After the housing was removed using a milling machine, the internal experiment sections were examined. All eight fiber-optic sensors were recovered, cut, and stored. The silicon carbide thermometry, temperature sensor, pressure sensor, lower spacer, and selected pressure and temperature cable sections were also removed and stored. The metal bellows of the pressure sensor was found to be plastically deformed, indicating that it had been properly pressurized during irradiation and generally behaved as expected. X-ray diffraction analysis of a section of one of the irradiated inductor cores within the pressure sensor was performed and confirmed the presence of phase-pure alpha ferrite (i.e., no unexpected phase transformations). Inductance testing was performed on the irradiated pressure sensor cores using an unirradiated test coil, and DC resistance measurements of the transceiver coils were also performed. The measurements with irradiated inductor cores assembled inside unirradiated coils showed slightly reduced inductance compared to measurements made with unirradiated cores, but the difference was not sufficient to explain the more significant reductions in inductance that were observed in-pile. Therefore, it is suspected that degradation of the inductor coils (specifically the wire wrapping) is responsible for the reduced inductance observed in-pile.

This report summarizes the in situ data collected during three cycles of irradiation (~75 days) of the Wireless Instrumented Removable Beryllium Experiment 2021 (WIRE-21) in the removable beryllium (RB) positions of the High Flux Isotope Reactor (HFIR). The experiment was designed primarily to evaluate the effects of high neutron flux and fluence on the performance of wireless temperature and pressure sensors being developed by Westinghouse Electric Company (WEC). WEC’s sensors could provide critical data regarding the evolution of centerline temperatures and pressurization due to fission gas release during fuel operation in light-water reactors (LWRs) or various advanced reactor applications. In addition to WEC’s wireless sensors, many other sensors were interrogated, including thermocouples, self-powered neutron detectors (SPNDs), distributed fiber optic temperature sensors, and passive neutron flux wires and silicon carbide thermometry. WIRE-21 was irradiated for a total of 75 effective full-power days over five full or partial HFIR cycles, resulting in maximum thermal and fast neutron fluences of 5.8 × 1021 and 3.4 × 1021 n/cm2, respectively. Although two exposed thermocouples located inside WEC’s sensors failed during the first irradiation cycle, the remaining 10 thermocouples that were functional at the start of the irradiation survived for the entire duration of the experiment. Measured temperatures were within the range of typical LWR operating conditions: most thermocouples reading in the ~300–400°C range. The four SPNDs all showed a measurable response to changes in reactor power, but each SPND responded differently. The fiber optic sensors show interesting evolutions in reflected signal intensities that depend significantly on the fiber dopants, type of fiber Bragg gratings (FBGs), and the light guiding mechanism (total internal reflection vs. photonic band gap). The discrepancies in the SPND data and the detailed evolution of the fiber optic sensors are being investigated by the Advanced Sensors and Instrumentation program of the US Department of Energy, Office of Nuclear Energy. Multiple temperature and pressure transients were actuated to compare the response of WEC’s sensors with reference thermocouples or ex-core pressure transducers, respectively. WEC’s sensors successfully captured all actuated temperature transients, even after accumulating fast neutron fluence on the order of 2 × 1021 n/cm2. Significant reductions in the inductance in WEC’s six inductors caused some drift in the wireless sensors. These effects appear to be related to rate effects (i.e., higher neutron flux), as they were not observed during previous testing at lower neutron flux. However, WEC’s temperature sensor remained functional even after the inductances decreased. Unfortunately, WEC’s pressure sensor showed no response during pressurization of the metal bellows. Post-irradiation examination will help inform why the sensor did not respond to changes in applied pressure and determine the mechanism for the decrease in inductances.

The ability to deploy new nuclear fuels for current or future reactor concepts requires a wealth of data regarding fuel performance during normal operation, anticipated operational occurrences, and design-basis accidents. Most of these data have historically been collected during experiments in materials test reactors, ideally with online instrumentation to collect as much data as possible. However, advanced instrumentation could also allow for in situ monitoring of fuel operating conditions during commercial reactor operation to maximize fuel utilization, reduce unnecessary conservativism in design margins, and improve operator understanding of limiting peaking factors. The latter approach would complicate fuel handling, particularly during refueling, unless the instrumentation could be placed inside the fuel rods and transmitted wirelessly to a receiver located outside the fuel’s primary pressure boundary. To this end, Westinghouse Electric Company (WEC) developed wireless sensors based on inductive coupling that can transmit information regarding fuel centerline temperatures and rod internal pressures wirelessly from within a fuel rod to a nearby instrument thimble. After testing these sensors in lower-power university research reactors, the next step is to perform high neutron fluence testing to characterize the performance of these wireless sensors under conditions that are more representative of the intended application—in this case, light-water reactors (LWRs). The removable Be (RB) positions of the High Flux Isotope Reactor (HFIR) at Oak Ridge National Laboratory (ORNL) provide the neutron flux, experiment volume, and access to instrument leads required to achieve these sensor testing goals. This report summarizes the design, analysis, and assembly of the Wireless Instrumented RB Experiment 2021 (WIRE-21). This is the most highly instrumented irradiation experiment ever performed in HFIR. The experiment will use seven different sensing techniques to measure temperature, pressure, neutron flux, and neutron fluence during reactor operation. In addition to WEC’s wireless temperature and pressure sensors, WIRE-21 includes an array of thermocouples, self-powered neutron detectors, spatially distributed fiber optic temperature sensors, passive SiC temperature monitors, and flux wires. The design of WIRE-21 and the cabling that was installed in HFIR also provide the infrastructure to enable accelerated, economical testing of advanced sensor technologies while leveraging the extremely high neutron flux that is available in HFIR. The containment for WIRE-21 is similar to previous RB irradiation vehicles but includes a few modifications, most notably the use of integrated compression seals to pass a larger number of sensor leads through the experiment’s pressure boundary. In addition to the sensor leads, inert gas lines are passed into the experiment to enable active temperature control and the ability to pneumatically actuate a bellows-driven pressure sensor. WIRE-21 is targeting component temperatures (300–350°C) and neutron fluence levels (~1022 n/cm2) that would be expected in the plenum region of LWR fuels, except for the active sensing region of the wireless temperature sensor, which is targeting LWR fuel centerline temperatures (~800–1,100°C). WIRE-21 was successfully assembled, passed all nondestructive examination, and was delivered to HFIR for insertion during upcoming cycle 498 (April 2022).
