Timothy Lach

High entropy alloys (HEAs) are promising materials for various applications including nuclear reactor environments. Thus, understanding their behavior under irradiation and exposure to different environments is important. Here, two sets of near-equiatomic CoCrCuFeNi thin films grown on either SiO₂/Si or Si substrates were irradiated at room temperature with 11.5 MeV Au ions, providing similar behavior to exposure to inert versus corrosion environments. The film grown on SiO₂ had relatively minimal change up to peak damage levels above 500 dpa, while the film grown on Si began intermixing at the substrate–film interface at peak doses of 0.1 dpa before transforming into a multi-silicide film at higher doses, all at room temperature with minimal thermal diffusion. The primary mechanism is radiation-enhanced diffusion via the inverse Kirkendall and solute drag effects. The results highlight how composition and environmental exposure affect the stability of HEAs under radiation and give insights into controlling these behaviors.

Characterizing oxide nuclear fuels is difficult due to complex fission products, which result from time-evolving system chemistry and extreme operating environments. Here, we report a machine learning-enhanced approach that accelerates the characterization of spent nuclear fuels and improves the accuracy of identifying nanophase fission products and bubbles. We apply this approach to commercial, high-burnup, irradiated light-water reactor fuels, demonstrating relationships between fission product precipitates and gases. We also gain understanding of the fission versus decay pathways of precipitates across the radius of a fuel pellet. An algorithm is provided for quantifying the chemical segregation of the fission products with respect to the high-burnup structure, which enhances our ability to process large amounts of microscopy data, including approaching the atomistic-scale. This may provide a faster route for achieving physics-based fuel performance modeling.

An amendment to this paper has been published and can be accessed via a link at the top of the paper.

We have made observations of noble metal phase fission-product agglomerates and gaseous xenon within the fuel-cladding interaction (FCI) zone of a high-burnup UO₂ fuel. The FCI is the boundary between the UO₂ pellet outer surface and the inner wall of the oxidized Zr-liner/cladding of the fuel rod. These fission-product agglomerates are well known to occur within the spent fuel matrix, and although radionuclides have been reported by others, we reveal aspects of their speciation and morphology. That they occur as discrete particles in the oxidized Zr liner, suggests the occurrence of hitherto unknown processes in the FCI zone during reactor operation, and this may have implications for the long-term storage and disposal of these types of materials. As expected, the particle agglomerates, which ranged in size from the nanometer scale to the micrometer scale, contained mainly Mo, Ru, Tc, Rh, and Pd; however, we also found significant quantities of Te associated with Pd. Indeed, we found nanometer scale separation of the distinct Pd/Te phase from the other fission products within the particles. Often associated with the particles was concentrations of uranium, sometimes appearing as a “cloud” with a tail emanating from the fuel into the oxidized cladding liner. Many of the noble metal phase particles appeared as fractured clusters separated by Xe-gas-filled voids. Possible mechanisms of formation or transport in the cladding liner are presented.

“Phase” map showing Noble metal phase particle (orange) and U fuel fragments (green and yellow) ejected into Zr cladding (red and blue) as a result of Xe bubble rupture.

Herein, the successful use of a focused ion beam/scanning electron microscope to prepare microsamples of radioactive single crystals for X-ray diffraction analysis is reported. This technique was used to extract and analyze crystalline Pu-containing particles as small as 28 µm³from Hanford soil taken from the 216-Z-9 waste crib, which were then crystallographically characterized using single-crystal X-ray diffraction to confirm the cubic structure of PuO₂. As a systematic proof of concept, the technique was first tested using UO₂crystals milled into cubic shapes with approximate volumes of 4620, 1331, 125, 8 and 1 µm³, in order to empirically determine the crystal size limits for characterization by a laboratory-based diffractometer with a sealed tube Mo or Ag anode X-ray source and a charge-coupled device detector.
