James Edgar

Developing advanced nuclear fuel technologies is critical for high-performance applications such as nuclear thermal propulsion (NTP). This study explores the feasibility of direct ink writing (DIW) for fabricating ceramic pellets for potential nuclear applications. Zirconium carbide (ZrC) is used as a matrix material and vanadium carbide (VC) is used as a surrogate for uranium carbide (UC) in this study. A series of ink formulations were developed with varying concentrations of VC and nanocrystalline cellulose (NCC) to optimize the rheological properties for DIW processing. Post-sintering analysis revealed that conventionally sintered samples at 1750 °C exhibited high porosity (>60%), significantly reducing the compressive strength compared to dense ZrC ceramics. However, increasing VC content improved densification and mechanical properties, albeit at the cost of increased shrinkage and ink flow challenges. Spark plasma sintering (SPS) achieved near-theoretical density (~97%) but introduced geometric distortions and microcracking. Despite these challenges, this study demonstrates that DIW offers a viable route for fabricating ZrC-based ceramic structures, provided that sintering strategies and ink rheology are further optimized. These findings establish a baseline for DIW of ZrC-based materials and offer valuable insights into the porosity control, mechanical stability, and processing limitations of DIW for future nuclear fuel applications.

Interest in hexagonal boron nitride (hBN) is booming due to its exceptional properties and potential applications: including a wide bandgap that emits deep ultraviolet light, its 2D structure, and its excellent chemical and thermal stability. In this work, intralayer carrier diffusion and exciton‐exciton annihilation in hBN are investigated by time‐resolved two‐color pump‐probe experiments. Two‐photon femtosecond excitation makes it possible to monitor the carrier relaxation dynamics in hBN under conditions of negligible surface recombination. A value of the two‐photon absorption coefficient β = 1.7 ± 0.5 cm GW⁻¹ is measured at 350 nm and its dependence in the 315–415 nm range. The obtained in‐plane exciton diffusivity increases with excitation power due to the screening of the exciton‐phonon interaction at high charge carrier densities between 10¹⁵ and 10¹⁷ cm⁻³. Conversely, the exciton‐exciton annihilation efficiency decreases by a factor of five from 80 to 600 K. Due to these efficient Auger processes, the in‐plane diffusion length in hBN is reduced from 0.24 to 0.1 µm as the excitation density increases. The robustness of the photoluminescence intensity is mediated in the high temperature range by excitons with a binding energy of 390 meV.

One of the main interests of 2D materials is their ability to be assembled with many degrees of freedom for tuning and manipulating excitonic properties. There is a need to understand how the structure of the interfaces between atomic layers influences exciton properties. Here we use cathodoluminescence and time-resolved cathodoluminescence experiments to study how excitons interact with the interface between two twisted hexagonal boron nitride (h-BN) crystals with various angles. An efficient capture of free excitons by the interface is demonstrated, which leads to a population of long-lived and interface-localized (2D) excitons. Temperature-dependent experiments indicate that for high twist angles, these excitons localized at the interface further undergo a self-trapping. It consists in a distortion of the lattice around the exciton on which the exciton traps itself. Our results suggest that this exciton-interface interaction causes the broad 4-eV optical emission of highly twisted h-BN–h-BN structures. Exciton self-trapping is finally discussed as a common feature of sp2 hybridized boron nitride polytypes and nanostructures due to the ionic nature of the B—N bond and the small size of their excitons.

van der Waals materials support numerous exotic polaritonic phenomena originating from their layered structures and associated vibrational and electronic properties. However, many van der Waals materials' unique properties are most prominent at cryogenic temperatures. This presents a particular challenge for polaritonics research, as reliable optical constant data are required for understanding light-matter coupling. This paper presents a cryogenic Fourier transform infrared microscope design constructed entirely from off-the-shelf components and associated fitting procedures for determining optical constants in the infrared. Data correction techniques were developed to directly quantify systematic errors in the fitting procedure. We use this microscope to present the first temperature-dependent characterization of the optical properties of hexagonal boron nitride enriched with isotopically pure boron. Our full analysis of the infrared dielectric function shows small but significant tuning of the optical constants, which is highly consistent with Raman data from the literature. We then use this dielectric data to perform and analyze the polariton propagation properties, which agree exceptionally well with published cryogenic scattering-type near-field microscopy results. In addition to the insights gained into hyperbolic polaritons in hBN, our paper represents a transferable framework for characterizing exfoliated infrared polaritonic materials and other infrared devices. This could accelerate discoveries in different material systems, especially those that are spatially inhomogeneous or cannot be prepared as large single crystals.

Deep ultraviolet (UV) photoluminescence (PL) and x-ray photoemission spectroscopy (XPS) were employed to investigate the origin of the atomic-like emission line at 4.09 eV from hexagonal boron nitride (h-BN) single crystals. High resolution XPS spectra analyzed by correlating PL spectra of the h-BN samples with and without the sharp emission line at 4.09 eV showed that carbon is bonding to both boron and nitrogen in the sample that has the 4.09 eV emission line. Our results showed that the defect responsible for the origin of the 4.09 eV line from h-BN is carbon related and it suggests that the defect structure has elemental carbon occupying both boron (CB) and as nitrogen (CN) sites.

Polar van der Waals (vdW) crystals, composed of atomic layers held together by vdW forces, can host phonon polaritons—quasiparticles arising from the interaction between photons in free-space light and lattice vibrations in polar materials. These crystals offer advantages such as easy fabrication, low Ohmic loss, and optical confinement. Recently, hexagonal boron nitride (hBN), known for having hyperbolicity in the mid-infrared range, has been used to explore multiple modes with high optical confinement. This opens possibilities for practical polaritonic nanodevices with subdiffractional resolution. However, polariton waves still face exposure to the surrounding environment, leading to significant energy losses. In this work, we propose a simple approach to inducing a hyperbolic phonon polariton (HPhP) waveguide in hBN by incorporating a low dielectric medium, ZrS2. The low dielectric medium serves a dual purpose—it acts as a pathway for polariton propagation, while inducing high optical confinement. We establish the criteria for the HPhP waveguide in vdW heterostructures with various thicknesses of ZrS2 through scattering-type scanning near-field optical microscopy (s-SNOM) and by conducting numerical electromagnetic simulations. Our work presents a feasible and straightforward method for developing practical nanophotonic devices with low optical loss and high confinement, with potential applications such as energy transfer, nano-optical integrated circuits, light trapping, etc.

In conventional thin materials, the diffraction limit of light constrains the number of waveguide modes that can exist at a given frequency. However, layered van der Waals (vdW) materials, such as hexagonal boron nitride (hBN), can surpass this limitation due to their dielectric anisotropy, exhibiting positive permittivity along one optic axis and negativity along the other. This enables the propagation of hyperbolic rays within the material bulk and an unlimited number of subdiffractional modes characterized by hyperbolic dispersion. By employing time-domain near-field interferometry to analyze ultrafast hyperbolic ray pulses in thin hBN, we showed that their zigzag reflection trajectories bound within the hBN layer create an illusion of backward-moving and leaping behavior of pulse fringes. These rays result from the coherent beating of hyperbolic waveguide modes but could be mistakenly interpreted as negative group velocities and backward energy flow. Moreover, the zigzag reflections produce nanoscale (60 nm) and ultrafast (40 fs) spatiotemporal optical vortices along the trajectory, presenting opportunities to chiral spatiotemporal control of light–matter interactions. Supported by experimental evidence, our simulations highlight the potential of hyperbolic ray reflections for molecular vibrational absorption nanospectroscopy. The results pave the way for miniaturized, on-chip optical spectrometers, and ultrafast optical manipulation.

The layered insulator hexagonal boron nitride (hBN) is a critical substrate that brings out the exceptional intrinsic properties of two‐dimensional (2D) materials such as graphene and transition metal dichalcogenides (TMDs). In this work, the authors demonstrate how hBN slabs tuned to the correct thickness act as optical waveguides, enabling direct optical coupling of light emission from encapsulated layers into waveguide modes. Molybdenum selenide (MoSe₂) and tungsten selenide (WSe₂) are integrated within hBN‐based waveguides and demonstrate direct coupling of photoluminescence emitted by in‐plane and out‐of‐plane transition dipoles (bright and dark excitons) to slab waveguide modes. Fourier plane imaging of waveguided photoluminescence from MoSe₂ demonstrates that dry etched hBN edges are an effective out‐coupler of waveguided light without the need for oil‐immersion optics. Gated photoluminescence of WSe₂ demonstrates the ability of hBN waveguides to collect light emitted by out‐of‐plane dark excitons.Numerical simulations explore the parameters of dipole placement and slab thickness, elucidating the critical design parameters and serving as a guide for novel devices implementing hBN slab waveguides. The results provide a direct route for waveguide‐based interrogation of layered materials, as well as a way to integrate layered materials into future photonic devices at arbitrary positions whilst maintaining their intrinsic properties.

Spin defects in van der Waals materials offer a promising platform for advancing quantum technologies. Here, we propose and demonstrate a powerful technique based on isotope engineering of host materials to significantly enhance the coherence properties of embedded spin defects. Focusing on the recently-discovered negatively charged boron vacancy center ($${{{{{{{{\rm{V}}}}}}}}}_{{{{{{{{\rm{B}}}}}}}}}^{-}$$ V B − ) in hexagonal boron nitride (hBN), we grow isotopically purified h¹⁰B¹⁵N crystals. Compared to $${{{{{{{{\rm{V}}}}}}}}}_{{{{{{{{\rm{B}}}}}}}}}^{-}$$ V B − in hBN with the natural distribution of isotopes, we observe substantially narrower and less crowded $${{{{{{{{\rm{V}}}}}}}}}_{{{{{{{{\rm{B}}}}}}}}}^{-}$$ V B − spin transitions as well as extended coherence time T₂ and relaxation time T₁. For quantum sensing, $${{{{{{{{\rm{V}}}}}}}}}_{{{{{{{{\rm{B}}}}}}}}}^{-}$$ V B − centers in our h¹⁰B¹⁵N samples exhibit a factor of 4 (2) enhancement in DC (AC) magnetic field sensitivity. For additional quantum resources, the individual addressability of the $${{{{{{{{\rm{V}}}}}}}}}_{{{{{{{{\rm{B}}}}}}}}}^{-}$$ V B − hyperfine levels enables the dynamical polarization and coherent control of the three nearest-neighbor ¹⁵N nuclear spins. Our results demonstrate the power of isotope engineering for enhancing the properties of quantum spin defects in hBN, and can be readily extended to improving spin qubits in a broad family of van der Waals materials.

Hyperbolic phonon polaritons (HPhPs) can be supported in materials where the real parts of their permittivities along different directions are opposite in sign. HPhPs offer confinements of long-wavelength light to deeply subdiffractional scales, while the evanescent field allows for interactions with substrates, enabling the tuning of HPhPs by altering the underlying materials. Yet, conventionally used noble metal and dielectric substrates restrict the tunability of this approach. To overcome this challenge, here we show that doped semiconductor substrates, e.g., InAs and CdO, enable a significant tuning effect and dynamic modulations. We elucidated HPhP tuning with the InAs plasma frequency in the near-field, with a maximum difference of 8.3 times. Moreover, the system can be dynamically modulated by photo-injecting carriers into the InAs substrate, leading to a wavevector change of ~20%. Overall, the demonstrated hBN/doped semiconductor platform offers significant improvements towards manipulating HPhPs, and potential for engineered and modulated polaritonic systems.

In this work, we report on the growth of hexagonal boron nitride (hBN) crystals from an iron flux at atmospheric pressure and high temperature and demonstrate that (i) the entire sheet of hBN crystals can be detached from the metal in a single step using hydrochloric acid and that (ii) these hBN crystals allow to fabricate high carrier mobility graphene-hBN devices. By combining spatially-resolved confocal Raman spectroscopy and electrical transport measurements, we confirm the excellent quality of these crystals for high-performance hBN-graphene-based van der Waals heterostructures. The full width at half maximum of the graphene Raman 2D peak is as low as 16 cm⁻¹, and the room temperature charge carrier mobilitiy is around 80 000 cm²/(Vs) at a carrier density 1 × 10¹² cm⁻¹². This is fully comparable with devices of similar dimensions fabricated using crystalline hBN synthesized by the high pressure and high temperature method. Finally, we show that for exfoliated high-quality hBN flakes with a thickness between 20 and 40 nm the line width of the hBN Raman peak, in contrast to the graphene 2D line width, is not useful for benchmarking hBN in high mobility graphene devices.

The ideal mechanical properties and behaviors of materials without the influence of defects are of great fundamental and engineering significance but considered inaccessible. Here, we use single-atom-thin isotopically pure hexagonal boron nitride (hBN) to demonstrate that two-dimensional (2D) materials offer us close-to ideal experimental platforms to study intrinsic mechanical phenomena. The highly delicate isotope effect on the mechanical properties of monolayer hBN is directly measured by indentation: lighter ¹⁰B gives rise to higher elasticity and strength than heavier ¹¹B. This anomalous isotope effect establishes that the intrinsic mechanical properties without the effect of defects could be measured, and the so-called ultrafine and normally neglected isotopic perturbation in nuclear charge distribution sometimes plays a more critical role than the isotopic mass effect in the mechanical and other physical properties of materials.

The boron-vacancy spin defect ($${\,{{\mbox{V}}}}_{{{\mbox{B}}}\,}^{-}$$ V B − ) in hexagonal boron nitride (hBN) has a great potential as a quantum sensor in a two-dimensional material that can directly probe various external perturbations in atomic-scale proximity to the quantum sensing layer. Here, we apply first-principles calculations to determine the coupling of the $${\,{{\mbox{V}}}}_{{{\mbox{B}}}\,}^{-}$$ V B − electronic spin to strain and electric fields. Our work unravels the interplay between local piezoelectric and elastic effects contributing to the final response to the electric fields. The theoretical predictions are then used to analyse optically detected magnetic resonance (ODMR) spectra recorded on hBN crystals containing different densities of $${\,{{\mbox{V}}}}_{{{\mbox{B}}}\,}^{-}$$ V B − centres. We prove that the orthorhombic zero-field splitting parameter results from local electric fields produced by surrounding charge defects. This work paves the way towards applications of $${\,{{\mbox{V}}}}_{{{\mbox{B}}}\,}^{-}$$ V B − centres for quantitative electric field imaging and quantum sensing under pressure.

Element isotopes are characterized by distinct atomic masses and nuclear spins, which can significantly influence material properties. Notably, however, isotopes in natural materials are homogenously distributed in space. Here, we propose a method to configure material properties by repositioning isotopes in engineered van der Waals (vdW) isotopic heterostructures. We showcase the properties of hexagonal boron nitride (hBN) isotopic heterostructures in engineering confined photon-lattice waves—hyperbolic phonon polaritons. By varying the composition, stacking order, and thicknesses of h¹⁰BN and h¹¹BN building blocks, hyperbolic phonon polaritons can be engineered into a variety of energy-momentum dispersions. These confined and tailored polaritons are promising for various nanophotonic and thermal functionalities. Due to the universality and importance of isotopes, our vdW isotope heterostructuring method can be applied to engineer the properties of a broad range of materials.

Hyperbolic phonon polaritons (HPhPs) can be supported in highly anisotropic materials, where the real parts of their permittivities along different directions are opposite in sign as a result of spectrally offset optical phonons. Compared to surface polaritons, HPhPs offer further confinement of long-wavelength light to deeply subdiffractional scales, and volume propagation that enables control of the polariton wavevector by changing the underlying medium. This allows for greater control of polaritonic resonators and near-field polariton propagation without deleterious etching of hyperbolic materials. Yet, conventionally used noble metal and dielectric substrates restrict the tunability of this approach, leaving most of the wavevector inaccessible. To overcome this challenge, we demonstrate that using doped semiconductors, e.g., InAs and CdO, can enable near-continuous tuning and access to both the maximum and minimum wavevectors (~8.3 times experimentally demonstrated). We further elucidate HPhP tuning with the plasma frequency of an InAs substrate, which features a significant wavevector discontinuity and modal order transition when the substrate permittivity crosses -1 in the Reststrahlen band. Around the transition point, the HPhP system is sensitive to perturbations, e.g., the working frequency, InAs plasma frequency and superstrate, thus it is suitable for sensing and modulation applications. We also illustrate that the hBN/InAs platform allows for active modulation at picosecond timescales by photo-injecting carriers into the InAs substrate, demonstrating a dynamic wavevector change of ~20%. Overall, the demonstrated hBN/doped semiconductor platform offers significant improvements towards manipulating HPhPs, and enormous potential for engineered and modulated polaritonic systems for applications in on-chip photonics and planar metasurface optics.

We visualized negative refraction of phonon polaritons, which occurs at the interface between two natural crystals. The polaritons—hybrids of infrared photons and lattice vibrations—form collimated rays that display negative refraction when passing through a planar interface between the two hyperbolic van der Waals materials: molybdenum oxide (MoO ₃ ) and isotopically pure hexagonal boron nitride (h ¹¹ BN). At a special frequency ω ₀ , these rays can circulate along closed diamond-shaped trajectories. We have shown that polariton eigenmodes display regions of both positive and negative dispersion interrupted by multiple gaps that result from polaritonic-level repulsion and strong coupling.

Phonon polariton (PhP) nanoresonators can dramatically enhance the coupling of molecular vibrations and infrared light, enabling ultrasensitive spectroscopies and strong coupling with minute amounts of matter. So far, this coupling and the resulting localized hybrid polariton modes have been studied only by far-field spectroscopy, preventing access to modal near-field patterns and dark modes, which could further our fundamental understanding of nanoscale vibrational strong coupling (VSC). Here we use infrared near-field spectroscopy to study the coupling between the localized modes of PhP nanoresonators made of h-BN and molecular vibrations. For a most direct probing of the resonator-molecule coupling, we avoid the direct near-field interaction between tip and molecules by probing the molecule-free part of partially molecule-covered nanoresonators, which we refer to as remote near-field probing. We obtain spatially and spectrally resolved maps of the hybrid polariton modes, as well as the corresponding coupling strengths, demonstrating VSC on a single PhP nanoresonator level. Our work paves the way for near-field spectroscopy of VSC phenomena not accessible by conventional techniques.

Scandium nitride (ScN) has recently attracted much attention for its potential applications in thermoelectric energy conversion, as a semiconductor in epitaxial metal/semiconductor superlattices, as a substrate for GaN growth, and alloying it with AlN for 5G technology. This study was undertaken to better understand its stoichiometry and electronic structure. ScN (100) single crystals 2 mm thick were grown on a single crystal tungsten (100) substrate by a physical vapor transport method over a temperature range of 1900–2000 °C and a pressure of 20 Torr. The core level spectra of Sc 2p3/2,1/2 and N 1s were obtained by x-ray photoelectron spectroscopy (XPS). The XPS core levels were shifted by 1.1 eV toward higher values as the [Sc]:[N] ratio varied from 1.4 at 1900 °C to ∼1.0 at 2000 °C due to the higher binding energies in stoichiometric ScN. Angle-resolved photoemission spectroscopy measurements confirmed that ScN has an indirect bandgap of ∼1.2 eV.

Quantized vortices are topological defects found in different two-dimensional geometries, from liquid crystals to ferromagnets, famously involved in spontaneous symmetry breaking and phase transitions. Their optical counterparts appear in planar geometries as a universal wave phenomenon, possessing topologically protected orbital angular momentum (OAM). So far, the spatio-temporal dynamics of optical vortices, including vortex-pair creation and annihilation, was observed only in Bose-Einstein condensates. Here we observe optical vortices in 2D materials and measure their dynamics, including events of pair-creation and annihilation. The vortices conserve their combined OAM during pair creation/annihilation events and determine the surrounding field profile throughout their motion between these events. The vortices are made of phonon polaritons in hexagonal boron nitride, which we directly probe using free electrons in an ultrafast transmission electron microscope. Our findings promote future investigations of vortex phenomena in 2D material platforms, toward their use for chiral plasmonics, quantum simulators, and control over selection rules in light-matter interactions.

Polaritons enable subwavelength confinement and highly anisotropic flows of light over a wide spectral range, holding the promise for applications in modern nanophotonic and optoelectronic devices. However, to fully realize their practical application potential, facile methods enabling nanoscale active control of polaritons are needed. Here, we introduce a hybrid polaritonic-oxide heterostructure platform consisting of van der Waals crystals, such as hexagonal boron nitride (hBN) or alpha-phase molybdenum trioxide (α-MoO₃), transferred on nanoscale oxygen vacancy patterns on the surface of prototypical correlated perovskite oxide, samarium nickel oxide, SmNiO₃ (SNO). Using a combination of scanning probe microscopy and infrared nanoimaging techniques, we demonstrate nanoscale reconfigurability of complex hyperbolic phonon polaritons patterned at the nanoscale with high resolution. Hydrogenation and temperature modulation allow spatially localized conductivity modulation of SNO nanoscale patterns, enabling robust real-time modulation and nanoscale reconfiguration of hyperbolic polaritons. Our work paves the way towards nanoscale programmable metasurface engineering for reconfigurable nanophotonic applications.

Spin defects in hexagonal boron nitride (hBN) are promising quantum systems for the design of flexible two-dimensional quantum sensing platforms. Here we rely on hBN crystals isotopically enriched with either ¹⁰B or ¹¹B to investigate the isotope-dependent properties of a spin defect featuring a broadband photoluminescence signal in the near infrared. By analyzing the hyperfine structure of the spin defect while changing the boron isotope, we first confirm that it corresponds to the negatively charged boron-vacancy center ($${{{{{{{{\rm{V}}}}}}}}}_{{{{{{{{\rm{B}}}}}}}}}^{-}$$ V B − ). We then show that its spin coherence properties are slightly improved in ¹⁰B-enriched samples. This is supported by numerical simulations employing cluster correlation expansion methods, which reveal the importance of the hyperfine Fermi contact term for calculating the coherence time of point defects in hBN. Using cross-relaxation spectroscopy, we finally identify dark electron spin impurities as an additional source of decoherence. This work provides new insights into the properties of $${{{{{{{{\rm{V}}}}}}}}}_{{{{{{{{\rm{B}}}}}}}}}^{-}$$ V B − spin defects, which are valuable for the future development of hBN-based quantum sensing foils.

Spin defects in hexagonal boron nitride (hBN) are promising quantum systems for the design of flexible two-dimensional quantum sensing platforms. Here we rely on hBN crystals isotopically enriched with either ¹⁰B or ¹¹B to investigate the isotope-dependent properties of a spin defect featuring a broadband photoluminescence signal in the near infrared. By analyzing the hyperfine structure of the spin defect while changing the boron isotope, we first confirm that it corresponds to the negatively charged boron-vacancy center ($${{{{{{{{\rm{V}}}}}}}}}_{{{{{{{{\rm{B}}}}}}}}}^{-}$$ V B − ). We then show that its spin coherence properties are slightly improved in ¹⁰B-enriched samples. This is supported by numerical simulations employing cluster correlation expansion methods, which reveal the importance of the hyperfine Fermi contact term for calculating the coherence time of point defects in hBN. Using cross-relaxation spectroscopy, we finally identify dark electron spin impurities as an additional source of decoherence. This work provides new insights into the properties of $${{{{{{{{\rm{V}}}}}}}}}_{{{{{{{{\rm{B}}}}}}}}}^{-}$$ V B − spin defects, which are valuable for the future development of hBN-based quantum sensing foils.

Negative reflection occurs when light is reflected toward the same side of the normal to the boundary from which it is incident. This exotic optical phenomenon is not only yet to be visualized in real space but also remains unexplored, both at the nanoscale and in natural media. Here, we directly visualize nanoscale-confined polaritons negatively reflecting on subwavelength mirrors fabricated in a low-loss van der Waals crystal. Our near-field nanoimaging results unveil an unconventional and broad tunability of both the polaritonic wavelength and direction of propagation upon negative reflection. On the basis of these findings, we introduce a device in nano-optics: a hyperbolic nanoresonator, in which hyperbolic polaritons with different momenta reflect back to a common point source, enhancing the intensity. These results pave way to realize nanophotonics in low-loss natural media, providing an efficient route to control nanolight, a key for future on-chip optical nanotechnologies.

The sp2-bonded layered compound boron nitride (BN) exists in more than a handful of different polytypes (i.e., different layer stacking sequences) with similar formation energies, which makes obtaining a pure monotype of single crystals extremely tricky. The co-existence of polytypes in a similar crystal leads to the formation of many interfaces and structural defects having a deleterious influence on the internal quantum efficiency of the light emission and on charge carrier mobility. However, despite this, lasing operation was reported at 215 nm, which has shifted interest in sp2-bonded BN from basic science laboratories to optoelectronic and electrical device applications. Here, we describe some of the known physical properties of a variety of BN polytypes and their performances for deep ultraviolet emission in the specific case of second harmonic generation of light.

The sp2-bonded layered compound boron nitride (BN) exists in more than a handful of different polytypes (i.e., different layer stacking sequences) with similar formation energies, which makes obtaining a pure monotype of single crystals extremely tricky. The co-existence of polytypes in a similar crystal leads to the formation of many interfaces and structural defects having a deleterious influence on the internal quantum efficiency of the light emission and on charge carrier mobility. However, despite this, lasing operation was reported at 215 nm, which has shifted interest in sp2-bonded BN from basic science laboratories to optoelectronic and electrical device applications. Here, we describe some of the known physical properties of a variety of BN polytypes and their performances for deep ultraviolet emission in the specific case of second harmonic generation of light.

Spin defects in hexagonal boron nitride (hBN) are promising quantum systems for the design of flexible two-dimensional quantum sensing platforms. Here we rely on hBN crystals isotopically enriched with either ¹⁰B or ¹¹B to investigate the isotope-dependent properties of a spin defect featuring a broadband photoluminescence signal in the near infrared. By analyzing the hyperfine structure of the spin defect while changing the boron isotope, we first unambiguously confirm that it corresponds to the negatively-charged boron-vacancy center (V_B^-). We then show that its spin coherence properties are slightly improved in ¹⁰B-enriched samples. This is supported by numerical simulations employing cluster correlation expansion methods, which reveal the importance of the hyperfine Fermi contact term for calculating the coherence time of point defects in hBN. Using cross-relaxation spectroscopy, we finally identify dark electron spin impurities as an additional source of decoherence. This work provides new insights into the properties of V_B^- spin defects, which are valuable for the future development of hBN-based quantum sensing foils.

Optical nanoantennas are of great importance for photonic devices and spectroscopy due to their capability of squeezing light at the nanoscale and enhancing light–matter interactions. Among them, nanoantennas made of polar crystals supporting phonon polaritons (phononic nanoantennas) exhibit the highest quality factors. This is due to the low optical losses inherent in these materials, which, however, hinder the spectral tuning of the nanoantennas due to their dielectric nature. Here, active and passive tuning of ultranarrow resonances in phononic nanoantennas is realized over a wide spectral range (≈35 cm⁻¹, being the resonance linewidth ≈9 cm⁻¹), monitored by near‐field nanoscopy. To do that, the local environment of a single nanoantenna made of hexagonal boron nitride is modified by placing it on different polar substrates, such as quartz and 4H‐silicon carbide, or covering it with layers of a high‐refractive‐index van der Waals crystal (WSe₂). Importantly, active tuning of the nanoantenna polaritonic resonances is demonstrated by placing it on top of a gated graphene monolayer in which the Fermi energy is varied. This work presents the realization of tunable polaritonic nanoantennas with ultranarrow resonances, which can find applications in active nanooptics and (bio)sensing.

Polaritons—confined light–matter waves—in van der Waals (vdW) materials are a research frontier in light–matter interactions with demonstrated advances in nanophotonics. Reflection, as a fundamental phenomenon involving waves, is particularly important for vdW polaritons, predominantly because it enables the investigation of polariton standing waves using the scanning probe technique. While previous works demonstrate a rigid phase ≈π/4 for the polariton reflection, herein is reported the altering of the polariton reflection phase by varying the geometry of polaritonic microstructures for the case study of hyperbolic surface polaritons (HSPs) in hexagonal boron nitride (hBN). Specifically, it is demonstrated that the polariton reflection phase can be systematically altered by varying the corner angle of the hBN microstructures, and that it experiences a π jump around a specific angle. This behavior, which is a consequence of the mathematical nature of the reflection coefficient, is therefore expected in other physical phenomena.

Phonons are important lattice vibrations that affect the thermal, electronic, and optical properties of materials. In this work, we studied infrared phonon resonance in a prototype van der Waals (vdW) material—hexagonal boron nitride (hBN)—with the thickness ranging from monolayers to bulk, especially on ultra-thin crystals with atomic layers smaller than 20. Our combined experimental and modeling results show a systematic increase in the intensity of in-plane phonon resonance at the increasing number of layers in hBN, with a sensitivity down to one atomic layer. While the thickness-dependence of the phonon resonance reveals the antenna nature of our nanoscope, the linear thickness-scaling of the phonon polariton wavelength indicates the preservation of electromagnetic hyperbolicity in ultra-thin hBN layers. Our conclusions should be generic for fundamental resonances in vdW materials and heterostructures where the number of constituent layers can be conveniently controlled. The thickness-dependent phonon resonance and phonon polaritons revealed in our work also suggest vdW engineering opportunities for desired thermal and nanophotonic functionalities.

Boron nitride (BN) layers with sp2 bonding have been grown by metal organic chemical vapor deposition on AlN underlayers, which are deposited on c-plane sapphire substrates. Two different boron precursors were employed—trimethylboron and triethylboron—while ammonia was used as the nitrogen precursor. The BN obtained epitaxial BN films contain ordered rhombohedral (rBN) and partially ordered turbostratic (tBN) stackings as evidenced by x-ray diffraction analysis. We discriminatively identify the PL signatures of the rBN and tBN from those typical of the hexagonal (hBN) and Bernal stackings (bBN). The optical signature of tBN appears at 5.45 eV, and it intercalates between the two recombination bands typical of rBN at 5.35 eV (strong intensity) and 5.55 eV(weaker intensity). The analogs of the high intensity band at 5.35 eV in rBN sit at 5.47 eV for hBN and at 5.54 eV for bBN.

Oscillatory magnetoresistance measurements on graphene have revealed a wealth of novel physics. These phenomena are typically studied at low currents. At high currents, electrons are driven far from equilibrium with the atomic lattice vibrations so that their kinetic energy can exceed the thermal energy of the phonons. Here, we report three non-equilibrium phenomena in monolayer graphene at high currents: (i) a “Doppler-like” shift and splitting of the frequencies of the transverse acoustic (TA) phonons emitted when the electrons undergo inter-Landau level (LL) transitions; (ii) an intra-LL Mach effect with the emission of TA phonons when the electrons approach supersonic speed, and (iii) the onset of elastic inter-LL transitions at a critical carrier drift velocity, analogous to the superfluid Landau velocity. All three quantum phenomena can be unified in a single resonance equation. They offer avenues for research on out-of-equilibrium phenomena in other two-dimensional fermion systems.

Hyperbolic phonon polaritons (HPhPs) in hexagonal boron nitride (hBN) enable the direct manipulation of mid‐infrared light at nanometer scales, many orders of magnitude below the free‐space light wavelength. High‐resolution monochromated electron energy‐loss spectroscopy (EELS) facilitates measurement of excitations with energies extending into the mid‐infrared while maintaining nanoscale spatial resolution, making it ideal for detecting HPhPs. The electron beam is a precise source and probe of HPhPs, which allows the observation of nanoscale confinement in HPhP structures and directly extract hBN polariton dispersions for both modes in the bulk of the flake and modes along the edge. The measurements reveal technologically important nontrivial phenomena, such as localized polaritons induced by environmental heterogeneity, enhanced and suppressed excitation due to 2D interference, and strong modification of high‐momenta excitations such as edge‐confined polaritons by nanoscale heterogeneity on edge boundaries. The work opens exciting prospects for the design of real‐world optical mid‐infrared devices based on hyperbolic polaritons.

Hyperbolic phonon polaritons (HPhPs) enable strong confinements, low losses, and intrinsic beam steering capabilities determined by the refractive index anisotropy—providing opportunities from hyperlensing to flat optics and other applications. Here, two scanning-probe techniques, photothermal induced resonance (PTIR) and scattering-type scanning near-field optical microscopy (s-SNOM), are used to map infrared (6.4–7.4 µm) HPhPs in large (up to 120 × 250 µm2) near-monoisotopic (>99% 10B) hexagonal boron nitride (hBN) flakes. Wide (≈40 µm) PTIR and s-SNOM scans on such large flakes avoid interference from polaritons launched from different asperities (edges, folds, surface defects, etc.) and together with Fourier analyses (0.05 µm−1 resolution) enable precise measurements of HPhP lifetimes (up to ≈4.2 ps) and propagation lengths (up to ≈25 and ≈17 µm for the first- and second-order branches, respectively). With respect to naturally abundant hBN, we report an eightfold improved, record-high (for hBN) propagating figure of merit (i.e., with both high confinement and long lifetime) in ≈99% 10B hBN, achieving, finally, theoretically predicted values. We show that wide near-field scans critically enable accurate estimates of the polaritons’ lifetimes and propagation lengths and that the incidence angle of light, with respect to both the sample plane and the flake edge, needs to be considered to extract correctly the dispersion relation from the near-field polaritons maps. Overall, the measurements and data analyses employed here elucidate details pertaining to polaritons’ propagation in isotopically enriched hBN and pave the way for developing high-performance HPhP-based devices.

Hyperbolic phonon polaritons (HPhPs) enable strong confinements, low losses, and intrinsic beam steering capabilities determined by the refractive index anisotropy—providing opportunities from hyperlensing to flat optics and other applications. Here, two scanning-probe techniques, photothermal induced resonance (PTIR) and scattering-type scanning near-field optical microscopy (s-SNOM), are used to map infrared (6.4–7.4 µm) HPhPs in large (up to 120 × 250 µm2) near-monoisotopic (>99% 10B) hexagonal boron nitride (hBN) flakes. Wide (≈40 µm) PTIR and s-SNOM scans on such large flakes avoid interference from polaritons launched from different asperities (edges, folds, surface defects, etc.) and together with Fourier analyses (0.05 µm−1 resolution) enable precise measurements of HPhP lifetimes (up to ≈4.2 ps) and propagation lengths (up to ≈25 and ≈17 µm for the first- and second-order branches, respectively). With respect to naturally abundant hBN, we report an eightfold improved, record-high (for hBN) propagating figure of merit (i.e., with both high confinement and long lifetime) in ≈99% 10B hBN, achieving, finally, theoretically predicted values. We show that wide near-field scans critically enable accurate estimates of the polaritons’ lifetimes and propagation lengths and that the incidence angle of light, with respect to both the sample plane and the flake edge, needs to be considered to extract correctly the dispersion relation from the near-field polaritons maps. Overall, the measurements and data analyses employed here elucidate details pertaining to polaritons’ propagation in isotopically enriched hBN and pave the way for developing high-performance HPhP-based devices.

Refraction between isotropic media is characterized by light bending towards the normal to the boundary when passing from a low- to a high-refractive-index medium. However, refraction between anisotropic media is a more exotic phenomenon which remains barely investigated, particularly at the nanoscale. Here, we visualize and comprehensively study the general case of refraction of electromagnetic waves between two strongly anisotropic (hyperbolic) media, and we do it with the use of nanoscale-confined polaritons in a natural medium: α-MoO₃. The refracted polaritons exhibit non-intuitive directions of propagation as they traverse planar nanoprisms, enabling to unveil an exotic optical effect: bending-free refraction. Furthermore, we develop an in-plane refractive hyperlens, yielding foci as small as λ_p/6, being λ_p the polariton wavelength (λ₀/50 compared to the wavelength of free-space light). Our results set the grounds for planar nano-optics in strongly anisotropic media, with potential for effective control of the flow of energy at the nanoscale.

Erbium nitride (ErN) is a rare-earth metal mononitride continuing to receive interest due to its unique electronic, magnetic, and optical properties. ErN has shown promise in the development of new functional materials for optoelectronic and spintronic devices. Here, we report on the optical properties of ErN crystals, grown by sublimation and probed by photoluminescence (PL) spectroscopy at both room temperature and 180 K. Multiple transition lines were observed between 2 and 4.5 eV. Using the PL results together with reported calculations, a coherent picture for the band structure at the Γ-point for ErN crystals was derived. PL results revealed that ErN has a minimum direct energy gap of 2.41 eV and a total of two valence bands and two conduction bands at the Γ-point separated by about 0.15 eV and 0.34 eV, respectively. These transitions reveal optical properties of ErN in the UV region and its band structure at the Γ-point.

Carrier doping is the basis of the modern semiconductor industry. Great efforts are put into the control of carrier doping for 2D semiconductors, especially the layered transition metal dichalcogenides. Here, the direct laser patterning of WSe₂ devices via light‐induced hole doping is systematically studied. By changing the laser power, scan speed, and the number of irradiation times, different levels of hole doping can be achieved in the pristine electron‐transport‐dominated WSe₂, without obvious sample thinning. Scanning transmission electron microscopy characterization reveals that the oxidation of the laser‐radiated WSe₂ is the origin of the carrier doping. Photocurrent mapping shows that after the same amount of laser irradiation, with increasing thickness, the laser patterned PN junction changes from the pure lateral to the vertical‐lateral hybrid structure, accompanied by the decrease in the open circuit voltage. The vertical‐lateral hybrid PN junction can be tuned to a pure lateral one by further irradiation, showing possibilities to construct complex junction profiles. Moreover, a NOR gate circuit is demonstrated by direct patterning of p‐doped channels using laser irradiation without introducing passive layers and metal electrodes with different work functions. This method simplifies device fabrication procedures and shows a promising future in large scale logic circuit applications.

Phonon‐polaritons, mixed excitations of light coupled to lattice vibrations (phonons), are emerging as a powerful platform for nanophotonic applications. This is because of their ability to concentrate light into extreme sub‐wavelength scales and because of their longer phonon lifetimes compared to their plasmonic counterparts. In this work, the infrared properties of phonon‐polaritonic nanoresonators made of monoisotopic ¹⁰B hexagonal boron nitride (h‐BN) are explored, a material with increased phonon‐polariton lifetimes compared to naturally abundant h‐BN due to reduced photon scattering from randomly distributed isotopes. An average relative improvement of 50% of the quality factor of monoisotopic h‐BN nanoresonators is obtained with respect to nanoresonators made of naturally abundant h‐BN, allowing for the sensing of nanometric‐thick films of molecules through both surface‐enhanced absorption spectroscopy and refractive index sensing. Further, even strong coupling between molecular vibrations and the phonon‐polariton resonance in monoisotopic h‐BN ribbons can be achieved.

Silicon waveguides have enabled large‐scale manipulation and processing of near‐infrared optical signals on chip. Yet, expanding the bandwidth of guided waves to other frequencies will further increase the functionality of silicon as a photonics platform. Frequency multiplexing by integrating additional architectures is one approach to the problem, but this is challenging to design and integrate within the existing form factor due to scaling with the free‐space wavelength. This paper demonstrates that a hexagonal boron nitride (hBN)/silicon hybrid waveguide can simultaneously enable dual‐band operation at both mid‐infrared (6.5–7.0 µm) and telecom (1.55 µm) frequencies, respectively. The device is realized via the lithography‐free transfer of hBN onto a silicon waveguide, maintaining near‐infrared operation. In addition, mid‐infrared waveguiding of the hyperbolic phonon polaritons (HPhPs) supported in hBN is induced by the index contrast between the silicon waveguide and the surrounding air underneath the hBN, thereby eliminating the need for deleterious etching of the hyperbolic medium. The behavior of HPhP waveguiding in both straight and curved trajectories is validated within an analytical waveguide theoretical framework. This exemplifies a generalizable approach based on integrating hyperbolic media with silicon photonics for realizing frequency multiplexing in on‐chip photonic systems.

When light-matter polaritons travel in periodic media, they acquire properties akin to Bloch quasi-particles in crystals.

Two-dimensional (2D) materials can confine light to volumes much shorter than the wavelength, and, together, the long propagation lengths make them attractive materials for developing nanophotonic platforms. Characterizing the spatiotemporal control of 2D polariton wave packets has been hindered for the same reasons that make their potential applications exciting: They have extremely small wavelengths and are strongly confined inside the material. Kurman et al. developed a new pump-probe technique based on electron emission that provides access to the spatiotemporal dynamics of 2D polaritons. The nanometric spatial resolution and femtosecond temporal resolution will be useful for probing the excitation dynamics of these materials.

Science , abg9015, this issue p. 1181

The limited memory retention for a ferroelectric field-effect transistor has prevented the commercialization of its nonvolatile memory potential using the commercially available ferroelectrics. Here, we show a long-retention ferroelectric transistor memory cell featuring a metal-ferroelectric-metal-insulator-semiconductor architecture built from all van der Waals single crystals. Our device exhibits 17 mV dec⁻¹ operation, a memory window larger than 3.8 V, and program/erase ratio greater than 10⁷. Thanks to the trap-free interfaces and the minimized depolarization effects via van der Waals engineering, more than 10⁴ cycles endurance, a 10-year memory retention and sub-5 μs program/erase speed are achieved. A single pulse as short as 100 ns is enough for polarization reversal, and a 4-bit/cell operation of a van der Waals ferroelectric transistor is demonstrated under a 100 ns pulse train. These device characteristics suggest that van der Waals engineering is a promising direction to improve ferroelectronic memory performance and reliability for future applications.

Polaritons – coupled excitations of photons and dipolar matter excitations – can propagate along anisotropic metasurfaces with either hyperbolic or elliptical dispersion. At the transition from hyperbolic to elliptical dispersion (corresponding to a topological transition), various intriguing phenomena are found, such as an enhancement of the photonic density of states, polariton canalization and hyperlensing. Here, we investigate theoretically and experimentally the topological transition, the polaritonic coupling and the strong nonlocal response in a uniaxial infrared-phononic metasurface, a grating of hexagonal boron nitride (hBN) nanoribbons. By hyperspectral infrared nanoimaging, we observe a synthetic transverse optical phonon resonance (strong collective near-field coupling of the nanoribbons) in the middle of the hBN Reststrahlen band, yielding a topological transition from hyperbolic to elliptical dispersion. We further visualize and characterize the spatial evolution of a deeply subwavelength canalization mode near the transition frequency, which is a collimated polariton that is the basis for hyperlensing and diffraction-less propagation.

Polaritons in two-dimensional materials provide extreme light confinement that is difficult to achieve with metal plasmonics. However, such tight confinement inevitably increases optical losses through various damping channels. Here we demonstrate that hyperbolic phonon polaritons in hexagonal boron nitride can overcome this fundamental trade-off. Among two observed polariton modes, featuring a symmetric and antisymmetric charge distribution, the latter exhibits lower optical losses and tighter polariton confinement. Far-field excitation and detection of this high-momenta mode become possible with our resonator design that can boost the coupling efficiency via virtual polariton modes with image charges that we dub ‘image polaritons’. Using these image polaritons, we experimentally observe a record-high effective index of up to 132 and quality factors as high as 501. Further, our phenomenological theory suggests an important role of hyperbolic surface scattering in the damping process of hyperbolic phonon polaritons.

We report the development of a scanning confocal microscope dedicated to photoluminescence in the 200 nm-wavelength range for samples at cryogenic temperatures (5 K–300 K). We demonstrate the performances of our deep ultraviolet cryomicroscope in high-quality hexagonal boron nitride (hBN) crystals, although it can be utilized for biological studies in its range of operating wavelengths. From the mapping of photoluminescence, we bring evidence for the suppression of extrinsic recombination channels in regions free from defects. The observation of emission spectra dominated by intrinsic recombination processes was never reported before in hBN by means of photoluminescence spectroscopy. We show that photoluminescence tomography now competes with cathodoluminescence and that deep ultraviolet cryomicroscopy by photoluminescence is a novel powerful tool in materials science applications, with the great advantage of an efficient non-invasive photo-excitation of carriers.

Hexagonal boron nitride (BN), one of the very few layered insulators, plays a crucial role in 2D materials research. In particular, BN grown with a high pressure technique has proven to be an excellent substrate material for graphene and related 2D materials, but at the same time very hard to replace. Here we report on a method of growth at atmospheric pressure as a true alternative for producing BN for high quality graphene/BN heterostructures. The process is not only more scalable, but also allows to grow isotopically purified BN crystals. We employ Raman spectroscopy, cathodoluminescence, and electronic transport measurements to show the high-quality of such monoisotopic BN and its potential for graphene-based heterostructures. The excellent electronic performance of our heterostructures is demonstrated by well developed fractional quantum Hall states, ballistic transport over distances around 10 µm at low temperatures and electron-phonon scattering limited transport at room temperature.

Erbium nitride (ErN) is a rare-earth metal mononitride with desirable electronic, magnetic, and optical properties. ErN can be incorporated into III-nitride semiconductors to develop new functional materials for optoelectronic and spintronic devices. Here, we report on the optical properties of ErN crystals, grown by sublimation and probed by photoluminescence (PL) spectroscopy. Three transition lines were observed near 1 eV. Theoretically, ErN has a small indirect energy gap of around 0.2 eV with a conduction band minimum at the X-point of the Brillouin zone and a valence band maximum at the Γ-point. The predicted smallest direct energy gap is around 1 eV, with two valence bands at the X-point. Using the PL results together with the reported calculations, a coherent picture for the band structure at the X-point for ErN crystals has been derived. Experimental results revealed that ErN has a minimum direct bandgap of 0.98 eV and a total of two valence bands separated by about 0.37 eV at the X-point.

In this study, the growth of scandium nitride (100) single crystals with high electron mobility and high thermal conductivity was demonstrated by physical vapor transport (PVT). Single crystals were grown in the temperature range of 1900 °C–2140 °C under a nitrogen pressure between 15 and 20 Torr. Single crystal tungsten (100) was used as a nearly lattice constant matched seed crystal. Growth for 20 days resulted in a 2 mm thick crystal. Hall-effect measurements revealed that the layers were n-type with a 300 K electron concentration and a mobility of 2.17 × 1021 cm−3 and 73 cm2/V s, respectively. Consequently, this ScN crystal had a low electrical resistivity, 3.94 × 10−5 Ω cm. The thermal conductivity was in the range of 51–56 W/m K, three times higher than those in previous reports for ScN thin films. This study demonstrates the viability of the PVT crystal growth method for producing high quality bulk scandium nitride single crystals.

Probing of polaritons in 2D materials is facilitated by spectroscopic imaging with nanometer spatial resolution. The combination of atomic force microscopy and infrared laser sources provides access for in situ mappings of phonon polaritons. Here, it is demonstrated that the photothermal‐based peak force infrared microscopy is capable of revealing phonon polaritons with high spatial resolution in isotopically pure hexagonal boron nitride microstructures without damaging the sample. To further improve the sensitivity, peak force infrared microscopy is enhanced with a scheme of multiple laser pulse excitation. The resulting method of multipulse peak force infrared microscopy can detect phonon polaritons with high sensitivity, which is particularly useful for probing polaritons in 2D materials with high damping characteristics.

An effective approach to reducing phonon polariton damping and manipulating phonon polariton excitation in hBNviapolarization control.

Van der Waals (vdW) materials host a variety of polaritons, which make them an emerging material platform for manipulating light at the nanoscale. Due to the layered structure of vdW materials, the polaritons can exhibit a hyperbolic dispersion and propagate as nanoscale‐confined volume modes in thin flakes. On the other hand, surface‐confined modes can be found at the flake edges. Surprisingly, the guiding of these modes in ribbons—representing typical linear waveguide structures—is widely unexplored. Here, a detailed study of hyperbolic phonon polaritons propagating in hexagonal boron nitride ribbons is reported. Employing infrared nanoimaging, a variety of modes are observed. Particularly, the fundamental volume waveguide mode that exhibits a cutoff width is identified, which, interestingly, can be lowered by reducing the waveguide thickness. Further, hybridization of the surface modes and their evolution with varying frequency and waveguide width are observed. Most importantly, it is demonstrated that the symmetrically hybridized surface mode does not exhibit a cutoff width, and thus enables linear waveguiding of the polaritons in arbitrarily narrow ribbons. The experimental data, supported by simulations, establish a solid basis for the understanding of hyperbolic polaritons in linear waveguides, which is of critical importance for their application in future photonic devices.

High-quality monoisotopic hBN were synthesized using Fe-Cr flux. Boron and nitrogen were dissolved at a high temperature, then hBN single crystals were precipitated during cooling process.

Peak force scanning near-field optical microscopy (PF-SNOM) is instrumental in exploring tomographic polaritonic behaviors of two-dimensional (2D) materials at the nanoscale.

Photonic crystals are commonly implemented in media with periodically varying optical properties. Photonic crystals enable exquisite control of light propagation in integrated optical circuits, and also emulate advanced physical concepts. However, common photonic crystals are unfit for in-operando on/off controls. We overcome this limitation and demonstrate a broadly tunable two-dimensional photonic crystal for surface plasmon polaritons. Our platform consists of a continuous graphene monolayer integrated in a back-gated platform with nano-structured gate insulators. Infrared nano-imaging reveals the formation of a photonic bandgap and strong modulation of the local plasmonic density of states that can be turned on/off or gradually tuned by the applied gate voltage. We also implement an artificial domain wall which supports highly confined one-dimensional plasmonic modes. Our electrostatically-tunable photonic crystals are derived from standard metal oxide semiconductor field effect transistor technology and pave a way for practical on-chip light manipulation.

At very small twist angles of ∼0.1°, bilayer graphene exhibits a strain-accompanied lattice reconstruction that results in submicron-size triangular domains with the standard, Bernal stacking. If the interlayer bias is applied to open an energy gap inside the domain regions making them insulating, such marginally twisted bilayer graphene is expected to remain conductive due to a triangular network of chiral one-dimensional states hosted by domain boundaries. Here we study electron transport through this helical network and report giant Aharonov-Bohm oscillations that reach in amplitude up to 50% of resistivity and persist to temperatures above 100 K. At liquid helium temperatures, the network exhibits another kind of oscillations that appear as a function of carrier density and are accompanied by a sign-changing Hall effect. The latter are attributed to consecutive population of the narrow minibands formed by the network of one-dimensional states inside the gap.

Hexagonal boron nitride (h-BN) has been predicted to exhibit an in-plane thermal conductivity as high as ~ 550 W m⁻¹ K⁻¹ at room temperature, making it a promising thermal management material. However, current experimental results (220–420 W m⁻¹ K⁻¹) have been well below the prediction. Here, we report on the modulation of h-BN thermal conductivity by controlling the B isotope concentration. For monoisotopic ¹⁰B h-BN, an in-plane thermal conductivity as high as 585 W m⁻¹ K⁻¹ is measured at room temperature, ~ 80% higher than that of h-BN with a disordered isotope concentration (52%:48% mixture of ¹⁰B and ¹¹B). The temperature-dependent thermal conductivities of monoisotopic h-BN agree well with first principles calculations including only intrinsic phonon-phonon scattering. Our results illustrate the potential to achieve high thermal conductivity in h-BN and control its thermal conductivity, opening avenues for the wide application of h-BN as a next-generation thin-film material for thermal management, metamaterials and metadevices.

Polaritons formed by the coupling of light and material excitations enable light-matter interactions at the nanoscale beyond what is currently possible with conventional optics. However, novel techniques are required to control the propagation of polaritons at the nanoscale and to implement the first practical devices. Here we report the experimental realization of polariton refractive and meta-optics in the mid-infrared by exploiting the properties of low-loss phonon polaritons in isotopically pure hexagonal boron nitride interacting with the surrounding dielectric environment comprising the low-loss phase change material Ge₃Sb₂Te₆. We demonstrate rewritable waveguides, refractive optical elements such as lenses, prisms, and metalenses, which allow for polariton wavefront engineering and sub-wavelength focusing. This method will enable the realization of programmable miniaturized integrated optoelectronic devices and on-demand biosensors based on high quality phonon resonators.

An understanding of the nucleation and growth of hexagonal boron nitride (hBN) on nickel substrates is essential to its development as a functional material.

Van der Waals materials and their heterostructures offer a versatile platform for studying a variety of quantum transport phenomena due to their unique crystalline properties and the exceptional ability in tuning their electronic spectrum. However, most experiments are limited to devices that have lateral dimensions of only a few micrometres. Here, we perform magnetotransport measurements on graphene/hexagonal boron-nitride Hall bars and show that wider devices reveal additional quantum effects. In devices wider than ten micrometres we observe distinct magnetoresistance oscillations that are caused by resonant scattering of Landau-quantised Dirac electrons by acoustic phonons in graphene. The study allows us to accurately determine graphene’s low energy phonon dispersion curves and shows that transverse acoustic modes cause most of phonon scattering. Our work highlights the crucial importance of device width when probing quantum effects and also demonstrates a precise, spectroscopic method for studying electron-phonon interactions in van der Waals heterostructures.

Scandium nitride single crystals (14–90 μm thick) were grown on a tungsten (100) single crystal substrate by physical vapor transport in the temperature range of 1850 °C–2000 °C and pressure of 15–35 Torr. Epitaxial growth was confirmed using in-plane ϕ scan and out-of-plane x-ray diffraction techniques which revealed that ScN exhibits cube-on-cube growth with a plane relationship ScN (001) ǁ W (001) and normal direction ScN [100] ǁ W [110]. Atomic force microscopy revealed that the surface roughness decreased from 83 nm to 18 nm as the growth temperature was increased. The x-ray diffraction rocking curve (XRC) widths decreased with temperature, indicating that the crystal quality improved as the growth temperature increased. The lowest XRC FWHM was 821 arcsec which is so far the lowest value reported for ScN. Scanning electron microscopy exhibited the formation of macrosteps and cracks on the crystal surface with the latter due to the mismatch of ScN and tungsten coefficients of thermal expansion.

Metasurfaces control light propagation at the nanoscale for applications in both free-space and surface-confined geometries. However, dynamically changing the properties of metasurfaces can be a major challenge. Here we demonstrate a reconfigurable hyperbolic metasurface comprised of a heterostructure of isotopically enriched hexagonal boron nitride (hBN) in direct contact with the phase-change material (PCM) single-crystal vanadium dioxide (VO₂). Metallic and dielectric domains in VO₂ provide spatially localized changes in the local dielectric environment, enabling launching, reflection, and transmission of hyperbolic phonon polaritons (HPhPs) at the PCM domain boundaries, and tuning the wavelength of HPhPs propagating in hBN over these domains by a factor of 1.6. We show that this system supports in-plane HPhP refraction, thus providing a prototype for a class of planar refractive optics. This approach offers reconfigurable control of in-plane HPhP propagation and exemplifies a generalizable framework based on combining hyperbolic media and PCMs to design optical functionality.

Ar plasma etching and annealing are highly robust in generating oxygen related single photon emitters in hBN.

Defect sensitive etching (DSE) was developed to estimate the density of non-basal plane dislocations in hexagonal boron nitride (hBN) single crystals. The crystals employed in this study were precipitated by slowly cooling (2–4 °C/h) a nickel-chromium flux saturated with hBN from 1500 °C under 1 bar of flowing nitrogen. On the (0001) planes, hexagonal-shaped etch pits were formed by etching the crystals in a eutectic mixture of NaOH and KOH between 450 °C and 525 °C for 1–2 min. There were three types of pits: pointed bottom, flat bottom, and mixed shape pits. Cross-sectional transmission electron microscopy revealed that the pointed bottom etch pits examined were associated with threading dislocations. All of these dislocations had an a-type burgers vector (i.e., they were edge dislocations, since the line direction is perpendicular to the [211¯0]-type direction). The pit widths were much wider than the pit depths as measured by atomic force microscopy, indicating the lateral etch rate was much faster than the vertical etch rate. From an Arrhenius plot of the log of the etch rate versus the inverse temperature, the activation energy was approximately 60 kJ/mol. This work demonstrates that DSE is an effective method for locating threading dislocations in hBN and estimating their densities.

Defect populations in B₁₂P₂ samples are analyzed through spectroscopic fingerprinting, by simulating the X-ray spectroscopic signatures of crystallographic point defects from first-principles within the density functional theory framework.

We employ X-ray absorption near-edge spectroscopy at the boron K-edge and the phosphorus L_2,3-edge to study the structural properties of cubic boron phosphide (c-BP) samples.

With the global shortage of 3He gas, researchers worldwide are looking for alternative materials for detecting neutrons. Among the candidate materials, semiconductors are attractive because of their light weight and ease in handling. Currently, we are looking into the suitability of boron arsenide (B12As2) for this specific application. As the first step in evaluating the material qualitatively, the photo-response of B12As2 bulk crystals to light with different wavelengths was examined. The crystals showed photocurrent response to a band of 407- and 470- nm blue light. The maximum measured photoresponsivity and the photocurrent density at 0.7 V for 470 nm blue light at room temperature were 0.25 A ⋅ W−1 and 2.47 mA ⋅ cm−2, respectively. In addition to photo current measurements, the electrical properties as a function of temperature (range: 50-320 K) were measured. Reliable data were obtained for the low-temperature I-V characteristics, the temperature dependence of dark current and its density, and the resistivity variations with temperature in B12As2 bulk crystals. The experiments showed an exponential dependence on temperature for the dark current, current density, and resistivity; these three electrical parameters, respectively, had a variation of a few nA to μA, 1-100 μA ⋅ cm−2 and 7.6x105-7.7x103 Ω ⋅ cm, for temperature increasing from 50 K to 320 K. The results from this study reported the first photoresponse and demonstrated that B12As2 is a potential candidate for thermal-neutron detectors.

With the global shortage of 3He gas, researchers worldwide are looking for alternative materials for detecting neutrons. Among the candidate materials, semiconductors are attractive because of their light weight and ease in handling. Currently, we are looking into the suitability of boron arsenide (B12As2) for this specific application. As the first step in evaluating the material qualitatively, the photo-response of B12As2 bulk crystals to light with different wavelengths was examined. The crystals showed photocurrent response to a band of 407- and 470- nm blue light. The maximum measured photoresponsivity and the photocurrent density at 0.7 V for 470 nm blue light at room temperature were 0.25 A ⋅ W−1 and 2.47 mA ⋅ cm−2, respectively. In addition to photo current measurements, the electrical properties as a function of temperature (range: 50-320 K) were measured. Reliable data were obtained for the low-temperature I-V characteristics, the temperature dependence of dark current and its density, and the resistivity variations with temperature in B12As2 bulk crystals. The experiments showed an exponential dependence on temperature for the dark current, current density, and resistivity; these three electrical parameters, respectively, had a variation of a few nA to μA, 1-100 μA ⋅ cm−2 and 7.6x105-7.7x103 Ω ⋅ cm, for temperature increasing from 50 K to 320 K. The results from this study reported the first photoresponse and demonstrated that B12As2 is a potential candidate for thermal-neutron detectors.

In contrast to other III-nitride semiconductors GaN and AlN, the intrinsic (or free) exciton transition in hexagonal boron nitride (h-BN) consists of rather complex fine spectral features (resolved into six sharp emission peaks) and the origin of which is still unclear. Here, the free exciton transition (FX) in h-BN bulk crystals synthesized by a solution method at atmospheric pressure has been probed by deep UV time-resolved photoluminescence (PL) spectroscopy. Based on the separations between the energy peak positions of the FX emission lines, the identical PL decay kinetics among different FX emission lines, and the known phonon modes in h-BN, we suggest that there is only one principal emission line corresponding to the direct intrinsic FX transition in h-BN, whereas all other fine features are a result of phonon-assisted transitions. The identified phonon modes are all associated with the center of the Brillouin zone. Our results offer a simple picture for the understanding of the fundamental exciton transitions in h-BN.

The surface preparation for depositing Al2O3 for fabricating Au/Ni/Al2O3/n-GaN (0001) metal oxide semiconductor (MOS) capacitors was optimized as a step toward realization of high performance GaN MOSFETs. The GaN surface treatments studied included cleaning with piranha (H2O2:H2SO4 = 1:5), (NH4)2S, and 30% HF etches. By several metrics, the MOS capacitor with the piranha-etched GaN had the best characteristics. It had the lowest capacitance–voltage hysteresis, the smoothest Al2O3 surface as determined by atomic force microscopy (0.2 nm surface roughness), the lowest carbon concentration (∼0.78%) at the Al2O3/n-GaN interface (from x-ray photoelectron spectroscopy), and the lowest oxide-trap charge (QT = 1.6 × 1011 cm−2eV−1). Its interface trap density (Dit = 3.7 × 1012 cm−2eV−1), as measured with photon-assisted capacitance– voltage method, was the lowest from conduction band-edge to midgap.

Icosahedral boron phosphide (B12P2) is a wide-bandgap semiconductor possessing interesting properties such as high hardness, chemical inertness, and the reported ability to self-heal from irradiation by high energy electrons. Here, the authors developed Cr/Pt and Ni/Au ohmic contacts to epitaxially grown B12P2 for materials characterization and electronic device development. Cr/Pt contacts became ohmic after annealing at 700 °C for 30 s with a specific contact resistance of 2 × 10−4 Ω cm2, as measured by the linear transfer length method. Ni/Au contacts were ohmic prior to any annealing, and their minimum specific contact resistance was ∼l–4 × 10−4 Ω cm2 after annealing over the temperature range of 500–800 °C. Rutherford backscattering spectrometry revealed a strong reaction and intermixing between Cr/Pt and B12P2 at 700 °C and a reaction layer between Ni and B12P2 thinner than ∼25 nm at 500 °C.

This research focuses on the benefits and properties of TiO2–Al2O3 nanostack thin films deposited on Ga2O3/GaN by plasma-assisted atomic layer deposition (PA–ALD) for gate dielectric development. This combination of materials achieved a high dielectric constant, a low leakage current, and a low interface trap density. Correlations were sought between the films' structure, composition, and electrical properties. The gate dielectrics were approximately 15 nm thick and contained 5.1 nm TiO2, 7.1 nm Al2O3, and 2 nm Ga2O3 as determined by spectroscopic ellipsometry. The interface carbon concentration, as measured by x-ray photoelectron spectroscopy depth profile, was negligible for GaN pretreated by thermal oxidation in O2 for 30 min at 850 °C. The RMS roughness slightly increased after thermal oxidation and remained the same after ALD of the nanostack, as determined by atomic force microscopy. The dielectric constant of TiO2–Al2O3 on Ga2O3/GaN was increased to 12.5 compared to that of pure Al2O3 (8–9) on GaN. In addition, the nanostack's capacitance–voltage (C-V) hysteresis was small, with a total trap density of 8.74 × 1011 cm−2. The gate leakage current density (J = 2.81 × 10−8 A/cm2) was low at +1 V gate bias. These results demonstrate the promising potential of PA–ALD deposited TiO2/Al2O3 for serving as the gate dielectric on Ga2O3/GaN based MOS devices.

This study compares the physical, chemical and electrical properties of Al₂O₃ thin films deposited on gallium polar c‐ and nonpolar m ‐plane GaN substrates by atomic layer deposition (ALD). Correlations were sought between the film's structure, composition, and electrical properties. The thickness of the Al₂O₃ films was 19.2 nm as determined from a Si witness sample by spectroscopic ellipsometry. The gate dielectric was slightly aluminum‐rich (Al:O=1:1.3) as measured from X‐ray photoelectron spectroscopy (XPS) depth profile, and the oxide‐semiconductor interface carbon concentration was lower on c ‐plane GaN. The oxide's surface morphology was similar on both substrates, but was smoothest on c ‐plane GaN as determined by atomic force microscopy (AFM). Circular capacitors (50‐300 μm diameter) with Ni/Au (20/100 nm) metal contacts on top of the oxide were created by standard photolithography and e‐beam evaporation methods to form metal‐oxide‐semiconductor capacitors (MOSCAPs). The alumina deposited on c ‐plane GaN showed less hysteresis (0.15 V) than on m ‐plane GaN (0.24 V) in capacitance‐voltage (CV) characteristics, consistent with its better quality of this dielectric as evidenced by negligible carbon contamination and smooth oxide surface. These results demonstrate the promising potential of ALD Al₂O₃ on c ‐plane GaN, but further optimization of ALD is required to realize the best properties of Al₂O₃ on m ‐plane GaN. (© 2014 WILEY‐VCH Verlag GmbH & Co. KGaA, Weinheim)

Hexagonal boron nitride (hBN) crystals enriched in ¹⁰B and ¹¹B isotopes were synthesized using a high temperature (1500° C) Ni-Cr-B reactive-precipitation growth under a N₂ atmosphere. Two growth mechanisms were observed: conventional defect-facilitated bulk growth which produced crystals with a platelet-like habit with width and thickness of 20-30 μm and 5 μm, respectively, and vapor-liquid-solid interface growth of hBN whiskers with lengths and diameters as large as 70 μm and 5 μm, respectively. Similar growth mechanisms were seen for samples enriched in either isotope. Isotopic analysis via secondary-ion mass spectrometry showed boron concentrations of 84.4 at% and 93.0 at% for the majority isotopes in the ¹⁰B-rich and ¹¹B-rich samples, respectively. Raman spectroscopy showed an increase in peak Raman shift for the ¹⁰B-rich sample, having two barely resolved peaks at 1393.5 and 1388.8 cm^-1, and a decrease for the ¹¹B-rich sample, having peak at 1359.5 cm^-1 (FWHM of 9.4 cm^-1), compared to that of natural hBN, with its peak at 1365.8 cm^-1 (FWHM of 10.3 cm^-1). Raman shift showed a linear trend with increasing ¹⁰B concentration allowing for a calibration curve to be developed to estimate ¹⁰B enrichment in hBN using non-destructive methods.

The benefits of dry oxidation of n ‐GaN for the fabrication of metal‐oxide‐semiconductor structures are reported. GaN thin films grown on sapphire by MOCVD were thermally oxidized for 30, 45 and 60 minutes in a pure oxygen atmosphere at 850 °C to produce thin, smooth GaO_x layers. The GaN sample oxidized for 30 minutes had the best properties. Its surface roughness (0.595 nm) as measured by atomic force microscopy (AFM) was the lowest. Capacitance‐voltage measurements showed it had the best saturation in accumulation region and the sharpest transition from accumulation to depletion regions. Under gate voltage sweep, capacitance‐voltage hysteresis was completely absent. The interface trap density was minimum (D_it = 2.75×10¹⁰ cm^–2eV^–1) for sample oxidized for 30 mins. These results demonstrate a high quality GaO_x layer is beneficial for GaN MOSFETs. (© 2014 WILEY‐VCH Verlag GmbH & Co. KGaA, Weinheim)

Hexagonal boron nitride (hBN) is an emerging material for the exploration of new physics in two-dimensional (2D) systems that are complementary to graphene. Nanotubes with a diameter (∼60 nm) that is much larger than the exciton binding energy in hBN have been synthesized and utilized to probe the fundamental optical transitions and the temperature dependence of the energy bandgap of the corresponding 2D hBN sheets. An excitonic transition at 5.901 eV and its longitudinal optical phonon replica at 5.735 eV were observed. The excitonic emission line is blue shifted by about 130 meV with respect to that in hBN bulk crystals due to the effects of reduced dimensionality. The temperature evolution of the excitonic emission line measured from 300 to 800 K revealed that the temperature coefficient of the energy bandgap of hBN nanotubes with large diameters (or equivalently hBN sheets) is about 0.43 meV/0K, which is a factor of about 5 times smaller than the theoretically predicted value for the transitions between the π and π* bands in hBN bulk crystals and 6 times smaller than the measured value in AlN epilayers with a comparable energy bandgap. The observed weaker temperature dependence of the bandgap than those in 3D hBN and AlN is a consequence of the effects of reduced dimensionality in layer-structured hBN.

The recombination processes of excitons in hexagonal boron nitride (hBN) have been probed using time-resolved photoluminescence. It was found that the theory for two-dimensional (2D) exciton recombination describes well the exciton dynamics in three-dimensional hBN. The exciton Bohr radius and binding energy deduced from the temperature dependent exciton recombination lifetime is around 8 Å and 740 meV, respectively. The effective masses of electrons and holes in 2D hBN deduced from the generalized relativistic dispersion relation of 2D systems are 0.54mo, which are remarkably consistent with the exciton reduced mass deduced from the experimental data. Our results illustrate that hBN represents an ideal platform to study the 2D optical properties as well as the relativistic properties of particles in a condensed matter system.

The indirect band gap of icosahedral B12As2 (IBA) has been determined by variable temperature photoluminescence measurements (8 K-294 K) on solution-grown bulk samples. In addition, evidence of three shallow acceptor levels and one shallow donor level is reported. The low-temperature spectra were characterized by broad and intense deep defect emission, donor-acceptor pair (DAP) bands, and exciton recombination. The appearance of DAP emission verifies the incorporation of a donor in IBA, which has not been reported previously. The temperature dependence of the free exciton (FE) intensity reflected a FE binding energy of 45 meV. The variation of the FE peak position with temperature was fitted with both Varshni and Pässler models to determine an expression for the temperature dependence of the indirect band gap. The resulting low and room temperature band gaps are Eg(0) = 3.470 eV and Eg(294 K) = 3.373 eV, respectively. The latter is not consistent with previous reports of the room temperature band gap, 3.20 eV and 3.47 eV, derived from band structure calculations and optical absorption, respectively. The origin of these discrepancies is discussed. The DAP spectra reveal three relatively shallow acceptors with binding energies of ≈175, 255, and 291 meV, and a shallow donor with binding energy ≈25 meV. Although the identity of the individual acceptors is not known, they appear to be associated with the light-hole band. The small donor binding energy is suggestive of an interstitial donor impurity, which is suspected to be Ni.

The polarity of rough and smooth grains in textured aluminum nitride boules were analyzed by transmission electron microscopy. Specifically, convergent beam electron diffraction method was applied to determine polarity. The grains corresponding to smooth and rough surfaces were identified as having Al and N polarities, respectively. Aluminum oxide (Al₂O₃) was observed to form at the grain boundaries. The oxide may precipitate due to the low mutual solubility between Al₂O₃ and AlN at the high crystal growth temperature (∼2000°C). Oxygen may be the cause of polarity inversion that leads to the formation of Al and N polar grains.

With a wide band gap of greater than 3.0 eV and the ability to self-heal from radiation damage, icosahedral boron arsenide (B₁₂As₂) is an apt candidate for use in next-generation betavoltaics. By capturing and converting high energy electrons from radioisotopes into usable electricity, “nuclear batteries” made from B₁₂As₂ could potentially power devices for decades. Compared to bulk crystals or epitaxial films, B₁₂As₂ nanowires may have lower defect densities or may even be defect-free, leading to better electrical properties and device performance. In our study, B₁₂As₂ nanowires were synthesized via vapor-liquid-solid (VLS) growth using platinum powder and nickel powder on silicon carbide and 20 nm thick nickel film on silicon substrates from 700 °C to 1200 °C. Platinum yielded the highest quality nanowires from 900 °C to 950 °C, resulting in platinum particles densely covered with wires formed by straight segments connected by sharp angular kinks. At these growth temperatures, diameters ranged from less than 30 nm to about 300 nm as determined by scanning electron microscopy and transmission electron microscopy. Growth temperatures of 850 °C or less produced curled wires 200-1000 nm in diameter. Transmission electron microscopy and selected area electron diffraction revealed excellent crystallinity in wires grown above 850 °C, while wires grown at or below 850 °C were partially amorphous. Wires grown from the 20 nm nickel film displayed similar morphologies at temperatures up to 850 °C; from 900 °C to 950 °C, straight, isolated wires were grown with diameters of 200-400 nm. Nickel powder only produced wires larger than 1 μm in diameter. The comparative quality and growth of B₁₂As₂nanowires will be discussed.

The present work reports on the defect-selective etching (DSE) for estimating dislocation densities in icosahedral boron arsenide (B₁₂As₂) crystals using molten potassium hydroxide (KOH). DSE takes advantage of the greater reactivity of high-energy sites surrounding a dislocation, compared to the surrounding dislocation-free regions. The etch pits per area are indicative of the defect densities in the crystals, as confirmed by x-ray topography (XRT). Etch pit densities were determined for icosahedral boron arsenide crystals produced from a molten nickel flux as a function of etch time (1-5 minutes) and temperature (400-700°C). The etch pits were predominately triangle shaped, and ranged in size from 5-25μm. The average etch pit density of the triangle and oval etch-pits was on the order of 5x10⁷cm^-2 and 3x10⁶cm^-2 (respectively), for crystals that were etched for two minutes at 550°C.

We report on the electrical properties of Al2O3 and TiO2 dielectrics in three different MOS capacitors of Al2O3/n-Si, TiO2/n-Si, and Al2O3/n-GaN. Hysteresis analysis of capacitance-voltage data and shifts in flat band voltages showed that the interface electrical quality of TiO2/Si was superior compared to that of Al2O3/Si and Al2O3/GaN. The growth temperature during atomic layer deposition were varied and Al2O3 deposited at 300°C on GaN and TiO2 deposited at 200°C on Si had better electrical property. The dielectric constant of the unannealed TiO2 was low and only the brookite crystalline phase of TiO2 was detected by XRD. The variation in the capacitance on some MOS capacitors was related to nonuniformities of the TiO2 oxide surface, as found from AFM images. The leakage current densities were low, as obtained from current-voltage measurement of Al2O3 and TiO2 gate oxide.

Elimination of degenerate epitaxy in the growth of icosahedral boron arsenide (B₁₂As₂, abbreviated as IBA) was achieved on m-plane 15R-SiC substrates and 4H-SiC substrates intentionally misoriented by 7 degrees from (0001) towards [1-100]. Synchrotron white beam x-ray topography (SWBXT) revealed that only single orientation IBA was present in the epitaxial layers demonstrating the absence of twin variants which dominantly constitute the effects of degenerate epitaxy. Additionally, low asterism in the IBA diffraction spots compared to those grown on other SiC substrates indicates a superior film quality. Cross-sectional high resolution transmission electron microscopy (HRTEM) and scanning transmission electron microscopy (STEM) both confirmed the absence of twins in the IBA films and their high quality. The ease of nucleation on the ordered step structures present on these unique substrates overrides symmetry considerations that drive degenerate epitaxy and dominates the nucleation process of the IBA.

The crystallographic properties of bulk icosahedral boron arsenide (B₁₂A_s2) crystals grown by precipitation from molten nickel solutions were characterized. Large crystals (5-8 mm) were produced by dissolving the boron in nickel at 1150°C for 48-72 hours, reacting with arsenic vapor, and slowly cooling to room temperature. The crystals varied in color from black and opaque to clear and transparent. Raman spectroscopy, x-ray topography (XRT), and defect selective etching revealed that the B₁₂As₂ single crystals were high quality with low dislocation densities. Furthermore, XRT results suggest that the major face of the plate-like crystals was (111) type, while (100), (010) and (001) type facets were also observed optically. The predominant defect in these crystals was edge character growth dislocations with a <001> Burgers vector, and <-110> line direction. In short, XRT characterization shows that solution growth is a viable method for producing good quality B₁₂As₂ crystals.

B 12 As 2 / SiC  pn heterojunction diodes based on the radiation-hard B12As2 deposited on (0001) n-type 4H–SiC via chemical vapor deposition were demonstrated. The diodes exhibit good rectifying behavior with an ideality factor of 1.8 and a leakage current as low as 9.4×10−6 A/cm2. Capacitance-voltage measurements using a two-frequency technique showed a hole concentration of ∼1.8–2.0×1017 cm−3 in B12As2 with a slight increase near the interface due to the presence of an interfacial layer to accommodate lattice mismatch. Band offsets between the B12As2 and SiC were estimated to be ∼1.06 eV and 1.12 eV for conduction band and valance band, respectively.

The thermal conductivity of icosahedral boron arsenide (B12As2) films grown on (0001) 6H–SiC substrates by chemical vapor deposition was studied by the 3ω technique. The room temperature thermal conductivity decreased from 27.0 to 15.3 W/m K as the growth temperature was decreased from 1450 to 1275 °C. This is mainly attributed to the differences in the impurity concentration and microstructure, determined from secondary ion mass spectrometry and high resolution transmission electron microscopy, respectively. Callaway’s theory was applied to calculate the temperature-dependent thermal conductivity, and the results are in good agreement with the experimental data. Seebeck coefficients were determined as 107 μV/K and 136 μV/K for samples grown at 1350 °C with AsH3/B2H6 flow ratio equals to 1:1 and 3:5, respectively.

The formation of ScAlN nanowires on ScN/6H‐SiC(0001) by hydride vapor phase epitaxy (HVPE) was analyzed. The diameters and lengths of the nanowires were 50 to 150 nm and 1 µm, respectively. The nanowires had a Al/Sc metal ratio of 95/5 as measured by energy dispersive analysis of X‐rays (EDX). The 4.84 Å unit cell periodicity along the length of the ScAlN nanowires was similar to that of pure AlN (4.98 Å), as measured by Fourier transforms of high resolution transmission electron microscopy images of a single nanowire. Only the (111) and (222) peaks of the ScN continuous film and the (0006) of the 6H‐SiC substrate were detected by θ‐2θ X‐ray diffraction. A tentative model, based on catalyst‐induced growth, is proposed to explain the unintentional formation of nanowires on the ScN film. This model is based on the production of volatile Al (possibly AlCl) by the reaction of the scandium metal source with the alumina reactor tube and subsequent reaction with hydrogen chloride. This reacts with ammonia in the deposition zone to create ScAlN nanowires, catalyzed by small ScAl clusters, which are spontaneously formed on the ScN film before the nanowire growth.

magnified image

SEM images of the ScAlN nanowires.

The yellow color of bulk AlN crystals was found to be caused by the optical absorption of light with wavelengths shorter than that of yellow. This yellow impurity limits UV transparency and hence restricts the applications of AlN substrates for deep UV optoelectronic devices. Here, the optical properties of AlN epilayers, polycrystalline AlN, and bulk AlN single crystals have been investigated using photoluminescence (PL) spectroscopy to address the origin of this yellow appearance. An emission band with a linewidth of ∼0.3 eV (at 10 K) was observed at ∼2.78 eV. We propose that the origin of the yellow color in bulk AlN is due to a band-to-impurity absorption involving the excitation of electrons from the valence band to the doubly negative charged state, (VAl2−), of isolated aluminum vacancies, (VAl)3−/2− described by VAl2−+hν=VAl3−+h+. In such a context, the reverse process is responsible for the 2.78 eV PL emission.

Raman scattering spectroscopy was used to study the spectral linewidth and frequency of characteristic phonon modes of boron arsenide (B12As2) as a function of temperature between 7 and 680 K. A combination of two- and three-phonon decay processes was found to dominate the dynamics of the intra-icosahedral phonon modes at 624, 682, and 742 cm−1, whilst two-phonon decay appears to be favored for the As–As stretch mode at 310 cm−1 and for the 506 cm−1 mode. Changes in frequency with temperature predominantly contain contributions from lattice expansion for all modes except the 506 cm−1 Eg mode, where contributions from phonon damping play a more significant role.

A detailed analysis of the microstructure in B12As2 epitaxial layers grown by chemical-vapor deposition on (0001) 6H-SiC substrates is presented. Synchrotron white beam x-ray topography enabled macroscopic characterization of the substrate/epilayer ensembles and revealed the presence of a quite homogeneous solid solution of twin and matrix epilayer domains forming a submicron mosaic structure. The basic epitaxial relationship was found to be (0001)B12As2⟨112¯0⟩B12As2∥(0001)6H-SiC⟨112¯0⟩6H-SiC and the twin relationship comprised a 180° (or equivalently 60°) rotation about [0001]B12As2 in agreement with previous reports. Cross-sectional high resolution transmission electron microscopy revealed the presence of a ∼200 nm thick disordered transition layer which was shown to be created by the coalescence of a mosaic of translationally and rotationally variant domains nucleated at various types of nucleation sites available on the (0001) 6H-SiC surface. In this transition layer, competition between the growth of the various domains is mediated in part by the energy of the boundaries created between them as they coalesce. Boundaries between translationally variant domains are shown to have unfavorable bonding configurations and hence high-energy. These high-energy boundaries can be eliminated during mutual overgrowth by the generation of a 1/3[0001]B12As2 Frank partial dislocation which effectively eliminates the translational variants. This leads to an overall improvement in film quality beyond thicknesses of ∼200 nm as the translational variants grow out leaving only the twin variants. (0003) twin boundaries in the regions beyond 200 nm are shown to possess fault vectors such as 1/6[11¯00]B12As2, which are shown to originate from the mutual shift between the nucleation sites of the respective domains.

AlN homoepilayers and heteroepilayers were grown on polar c-plane and nonpolar a-plane and m-plane orientations of AlN bulk and sapphire substrates by metal organic chemical vapor deposition. A systematic comparative study of photoluminescence properties of these samples revealed that all AlN homoepilayers (c, a and m planes) were strain free with an identical band gap of about 6.099 (6.035)eV at 10 (300)K, which is about 42meV below the band gap of c-plane AlN heteroepilayers grown on sapphire. Also, nonpolar a-plane homoepilayers have the highest emission intensity over all other types of epilayers. We believe that a-plane AlN homoepilayers have the potential to provide orders of magnitude improvement in the performance of new generation deep UV photonic devices.

Single crystal, heteroepitaxial growth of icosahedral B12As2 (IBA, a boride semiconductor) on m-plane 15R-SiC is demonstrated. Previous studies of IBA on other substrates, i.e., (111)Si and (0001)6H-SiC, produced polycrystalline and twinned epilayers. In contrast, single-crystalline and untwinned IBA was achieved on m-plane 15R-SiC. Synchrotron white beam x-ray topography, Raman spectroscopy, and high resolution transmission electron microscopy confirm the high quality of the films. High quality growth is shown to be mediated by ordered nucleation of IBA on (474) substrate facets. This work demonstrates that m-plane 15R-SiC is a good substrate choice to grow high-quality untwinned IBA epilayers for future device applications.

This paper describes monolayer formation of octadecylphosphonic acid (ODPA) on GaN surfaces via self-assembly. Adsorption of a series of primarily substituted hydrocarbons (RX; -X = -OH, -NH2, -COOH, -SH, -PO(OH)2) from their toluene solutions was systematically studied on undoped, Ga-face GaN films prepared on sapphire (0001) substrates. ODPA forms a well-packed monolayer on GaN, especially when the GaN has an oxide surface layer, as suggested by the very high water contact angle of ODPA-coated GaN. In contrast, the other compounds did not give such high water contact angle. Atomic force microscopy images of GaN surfaces with and without ODPA are similar, suggesting the formation of a very thin and uniform film. The surface oxide layer and the monolayer formation of ODPA were assessed using X-ray photoelectron spectroscopy. These results indicate that an oxidized GaN surface can be modified with a well-packed monolayer of molecules having a phosphonate moiety.

The advantages of depositing AlN–SiC alloy transition layers on SiC substrates before the seeded growth of bulk AlN crystals were examined. The presence of AlN–SiC alloy layers helped to suppress the SiC decomposition by providing vapor sources of silicon and carbon. In addition, cracks in the final AlN crystals decreased from ∼5 × 10⁶/mm² for those grown directly on SiC substrates to less than 1 × 10⁶/mm² for those grown on AlN–SiC alloy layers because of the intermediate lattice constants and thermal expansion coefficient of AlN–SiC. X-ray diffraction confirmed the formation of pure single-crystalline AlN upon both AlN–SiC alloys and SiC substrates. X-ray topography (XRT) demonstrated that strains present in the AlN crystals decreased as the AlN grew thicker. However, the XRT for AlN crystals grown directly on SiC substrates was significantly distorted with a high overall defect density compared to those grown on AlN–SiC alloys.

The ability to control the resistivity of the wide band gap semiconductor B12As2 by doping with silicon was verified. The electrical properties of nominally undoped and Si-doped rhombohedral B12As2 thin films on semi-insulating 6H-SiC (0001) substrates prepared by chemical vapor deposition were subjected to Hall effect measurements. Varying the Si concentration in the B12As2 thin films from 7×1018to7×1021at.∕cm3 (as measured by secondary ion mass spectrometry) decreased the resistivities of the p-type B12As2 films from 2×105to10Ωcm. The resistivities of the B12As2 films were decreased by one to two orders of magnitude after rapid thermal annealing for 30s in argon. The spatial distribution of the hydrogen concentration was measured before and after annealing. No changes were detected, casting doubt on hydrogen as being the cause for the change in the resistivities of the B12As2 films with annealing.

Characterization of surface morphology and crystal defects is reported for homoepitaxial 4H-SiC films grown at high rates (35–40μm∕h) using methyltrichlorosilane (CH3SiCl3), as single precursor. The ratio of hydrogen to argon (H2∕Ar) in the carrier gas was varied to determine the effect of hydrogen on the surface morphology and the crystalline defects. Due to hydrogen’s reaction with the graphite heater, adjusting the H2∕Ar ratio effectively changed the C∕Si ratio in the gas phase; thereby, influencing surface roughness and dislocation density. Low H2∕Ar ratios of 0.1 and 0.125 produced smooth surfaces without step bunching. Higher H2∕Ar ratios of 0.2 and 0.33 enhanced the conversion of basal plane dislocations into threading edge dislocations and reduced the density of basal plane dislocations to approximately 600cm−2. However, at these H2∕Ar ratios, macrosteps formed on the surface and the roughness increased. Micropipes from substrate dissociated into closed-core threading screw dislocations in the films grown with H2∕Ar ratio in the range of 0.1–0.2. At H2∕Ar ratio of 0.33, micropipes propagated into the film, generating hollow-core threading screw dislocations.

The crystal structure and compositional changes near the two interfaces of a AlN/(AlN)_x (SiC)_1–x /4H‐SiC heterostructure prepared by sublimation‐recondensation growth were examined by cross‐sectional transmission electron microscopy. Deposition of an (AlN)_x (SiC)_1–x layer between a SiC seed and a bulk AlN crystal is potentially beneficial for gradually changing the lattice constants and coefficient of thermal expansion from SiC to AlN. A compositional transition layer adjacent to the 4H‐SiC substrate suggested interdiffusion between the substrate and the alloy layer. The alloy had the 4H‐polytype crystal structure in this layer; above the layer, the alloy exhibited the typical 2H‐polytype. Voids were present at the AlN/(AlN)_x (SiC)_1–x interface, due to the decomposition of the (AlN)_x (SiC)_1–x layer before the AlN layer had completely coalesced. The nominally pure AlN layer contained approximately 8% of Si and C, possibly coming from the decomposition of the alloy layer and/or the substrate during growth of the AlN layer. Both interfaces were abrupt, to less than 50 nm, with low densities of threading dislocations. Dislocations in both the (AlN)_x (SiC)_1–x and AlN layers were not threading, but ran parallel to the (0001) planes. (© 2006 WILEY‐VCH Verlag GmbH & Co. KGaA, Weinheim)

The oxidation kinetics, morphology, and crystallinity of aluminum nitride (AlN) powder thermally oxidized in flowing oxygen were determined from 800° to 1150°C. At 800°C the oxidation became detectable with weight change. AlN powder was almost completely oxidized at 1050°C after only 0.5 h. Amorphous aluminum oxide formed at relatively low temperatures (800°–1000°C), with a linear oxidation rate governed by the oxygen–nitride interfacial reaction. Transmission electron microscopy displayed individual aluminum oxide grains which formed a discontinuous oxide layer at this temperature range. The aluminum oxide was crystalline at higher temperatures (>1000°C), as detected by X‐ray diffraction, and the density of oxide grains increased with temperature.

Palladium, Pt, and Cr∕Pt contacts to the wide band gap icosahedral boride semiconductor B12As2 have been studied. All Pd and Pt contacts exhibited nonlinear I-V characteristics, while Cr∕Pt contacts were Ohmic. The specific contact resistance was reduced from 6Ωcm2 as-deposited to 3×10−4Ωcm2 after the Cr∕Pt contacts were annealed at 750°C for 30s in Ar. Annealing at 600°C or higher drastically reduced the semiconductor sheet resistance, whether annealing was performed before or after metallization. This apparent activation of the semiconductor is a likely cause for the improvement in the Ohmic contacts with annealing.

We report a Raman spectroscopy study of B12As2 under hydrostatic pressure up to 15 GPa. Mode Grüneisen parameters were determined for the B12As2 phonon modes. Phonon modes attributed to the As–As chain have a weak pressure dependence (0.6–1.9 cm−1 GPa−1) relative to inter- and intra-icosahedral vibrations (3.4–6.6 cm−1 GPa−1). The pressure dependence of B12As2 phonon frequencies is compared to those reported for α-boron and the origin of the mode at 505 cm−1 with its weak pressure dependence is discussed.

The stress distribution in bulk AlN crystals seeded on 6H–SiC was theoretically modeled and also determined experimentally from Raman peak positions. The full width at half maximum of the AlN Raman peaks showed the crystal quality improved as its thickness increased. The theoretical frequency shifts of the E1 (transverse optical) mode calculated from model-predicted stress were in good agreement with experimental values taken along the edges of crystal samples. The stress was linearly distributed along the depth of the samples, and changed from compressive at the growing surface to tensile at the interface between AlN and SiC for thickness range of several hundred micrometers. Large tensile stresses, up to 0.6 GPa, were detected in the AlN at the interface. The effects of growth temperature and sample thickness were investigated. It is predicted that the AlN on 6H–SiC must be at least 2 mm thick to prevent it from cracking while cooling down the sample from a growth temperature of 2000 °C.

We report on the Raman analysis of wurtzite single-crystalline bulk AlN under hydrostatic pressures up to 10 GPa. The pressure dependence of the AlN phonon frequencies was investigated. Mode Grüneisen parameters of 1.39, 1.57, 1.71, 0.93, and 1.26 were determined for the A1 (TO), E1 (TO), E2 (high), A1 (LO), and the quasi-longitudinal optical phonons, respectively. Recent theoretical calculations underestimate the pressure-induced frequency shift of the AlN phonons by about 20%–30%. Mode Grüneisen parameters of AlN were compared to those of GaN.

We report on the Raman analysis of the phonon lifetimes of the A1(LO) (longitudinal optical) and E2(high) phonons in bulk AlN crystals and their temperature dependence from 10 to 1275 K. Our experimental results show that amongst the various possible decay channels, the A1(LO) phonons decay primarily into two phonons of equal energy (Klemens model), most likely longitudinal-acoustic phonons, whereas the E2(high) phonon decays asymmetrically into a high-energy and a low-energy phonon. Possible decay channels of the E2(high) phonon have been shown to include combinations of E2(low) and acoustic phonons. Phonon lifetimes of the A1(LO) phonon and the E2(high) phonon of 0.75 and 2.9 ps, respectively, were measured at 10 K.

Boron was incorporated into GaN in order to determine its limits of solubility, its ability of reducing the lattice constant mismatch with 6H-SiC, as well as its effects on the structural and optical properties of GaN epilayers. B_xGa_1−xN films were deposited on 6H-SiC (0001) substrates at 950 °C by low pressure MOVPE using diborane, trimethylgallium, and ammonia as precursors. A single phase alloy with x=0.015 was successfully produced at a gas reactant B/Ga ratio of 0.005. Phase separation into pure GaN and B_xGa_1−xN alloy with x=0.30 was deposited for a B/Ga reactant ratio of 0.01. This is the highest B fraction of the wurtzite structure alloy ever reported. For B/Ga ratio ≥ 0.02, no B_xGa_1−xN was formed, and the solid solution contained two phases: wurtzite GaN and BN based on the results of Auger and x-ray diffraction. The band edge emission of B_xGa_1−xN varied from 3.451 eV for x=0 with FWHM of 39.2 meV to 3.465 eV for x=0.015 with FWHM of 35.1 meV. The narrower FWHM indicated that the quality of GaN epilayer was improved with small amount of boron incorporation.

The effect of substrate temperature on the growth rate, crystal grain size, and SiO2 mask stability in the selective epitaxial growth of silicon carbide deposited from SiH4, C2H4, and HCl1 on silicon dioxide masked silicon (100) was examined. Depositing at atmospheric pressure and a Cl/Si input ratio of 50 to achieve good selectivity, increasing the substrate temperature from 950 to 1000 °C increased the growth rate and the crystal size, and improved the film’s surface morphology, but also enhanced the SiO2 mask degradation rate, causing a loss of selectivity for long deposition times. For prolonged deposition times at 1000 °C, SiC nucleation occurred at both voids formed in the mask from its reaction with the silicon substrate and on the SiO2 mask itself—a consequence of increasing oxide surface roughness.

A detailed double crystal x-ray diffractometry study of epitaxial AlN thin films grown on sapphire, silicon and silicon carbide substrates was carried out to compare the structure, residual stress and defect concentration in these thin films. The structure of AlN is wurtzite with a small distortion in lattice parameters. This results in a small residual stress of the order of 109 dynes/cm2 in the film and can be accounted for from the difference in thermal expansion coefficients between the film and substrate. Both the x-ray and transmission electron microscopy measurements indicate a low defect density in the AlN thin film grown on 6H-SiC substrate which could be attributed to the small difference in lattice parameters between AlN and 6H-SiC.

Epitaxial layers of GaN on sapphire substrates have been grown by metalorganic chemical-vapor deposition at a deposition temperature as low as 400 °C, which is the lowest temperature for successful epitaxial growth of GaN by any technique. This is achieved by controlling the low flow rate of the source gases and by first depositing an AlN buffer layer at 400 °C. Low-temperature photoluminescence measurements have been employed to study the optical properties of the films deposited at different temperatures.

Both 3C-SiC and 6H-SiC single-crystal films can be grown on vicinal (0001) 6H-SiC wafers. We have found that oxidation can be a powerful diagnostic process for (1) ‘‘color mapping’’ the 3C and 6H regions of these films, (2) decorating stacking faults in the films, (3) enhancing the decoration of double positioning boundaries, and (4) decorating polishing damage. Contrary to previously published oxidation results, proper oxidation conditions can yield interference colors that provide a definitive map of the polytype distribution for both the Si face and C face of SiC films. Defects were more effectively decorated by oxidation on the Si face than on the C face.

We have found that, with proper pregrowth surface treatment, 6H-SiC single-crystal films can be grown by chemical vapor deposition (CVD) at 1450 °C on vicinal (0001) 6H-SiC with tilt angles as small as 0.1°. Previously, tilt angles of greater than 1.5° were required to achieve 6H on 6H at this growth temperature. In addition, 3C-SiC could be induced to grow within selected regions on the 6H substrate. The 3C regions contained few (or zero) double-positioning boundaries and a low density of stacking faults. A new growth model is proposed to explain the control of SiC polytype in this epitaxial film growth process.
