Massachusetts Institute of Technology Reactor (MITR)
Massachusetts Institute of Technology Massachusetts
- Institution Name
- Massachusetts Institute of Technology
- Name
- Massachusetts Institute of Technology Reactor (MITR)
- Building
- Nuclear Reactor Laboratory
- Primary Facility Type
- Reactor
- Secondary Facility Type
- Neutron Beam
- Tertiary Facility Type
- Post Irradiation Examination
- Reactor Type
- Tank-type research reactor
- Thermal Power (MW)
- 6
- Pulse Power
- 0
- Thermal Flux (n/cm^2/s)
- 1.2 x 10^14
- Fast Flux (n/cm^2/s)
- 5 x 10^13
- In Core Locations
- 3: not permanently installed, 1 gas-filled static capsule tube
- Ex Core Locations
- 6: vertical graphite locations
- PTS
- 2: 2-inch high flux and 1-inch intermediate flux
- Flow Loops
- 3: not permanently installed
- Beam Ports
- 9: One 12-inch radial, two 6-inch radial, one 6-inch through-port, four 4-inch radial, one 4-inch through-port, two shielded rooms: one with high flux vertical thermal beam and one with horizontal 1m2 fission neutron beam
- Operating Cycle
- 10 weeks up / 2 weeks down, 24 hours/day at 7 days/week for 6 weeks with one week outage
- Comments
- 70 kW/L power density, maximum temperature is 50C.
- Sample Size
- 1.8 inch diameter
- Core Sample Height
- 24 inches
- Core Functions
- The Massachusetts Institute of Technology’s Nuclear Reactor Laboratory (MIT NRL) operates the MITR-II 6MW research reactor on the MIT main campus. The NRL specializes in development of new irradiation experiments, materials and instrumentation testing in extreme environments, utilizing irradiation to probe the properties of materials, and the analysis of irradiated specimens.
- Unique Functions
- MITR provides in-core and out-of-core thermal and fast neutron irradiation of nuclear fuels and material experiments, in addition to gamma irradiation using spent fuel. We offer in-core flow loops at LWR conditions that can use BWR or PWR chemistry. And we can perform in-core flow loop irradiation testing for high temp gas reactor materials loop up to 1600C.
- Hotwork Facilities
- Hot cells and hot sample prep facilities are available in containment building and restricted area.
- Support Equipment
- Polar crane with 20T and 3T capability
- Radiological Limit
- <100mr/hr @ 30cm
- Materials Allowed
- alpha/beta/gamma
- Sample Encapsulation
- In-core experiments can have 100g U-235 equivalent samples with double encapsulation.
- Atmosphere
- air/water/inert gases
- Commissioning Date
- 1958
- Recent Upgrade
- 2016
- RAM License
- NRC/MA
- License End Date
- 2030
- Docket Number
- 50020
- User Facility
- Yes
- User Org Web Page
- nsuf.inl.gov
- Proposal Web Page
- nsuf.inl.gov
- GAIN Partner
- No
- NSUF Partner
- Yes
- NE Use Percentage
- No NE Use Percentage Defined
- Utilization Hours
- 4000 hr/year
- Number Of Users
- No Number Of Users Defined
- Number Of Staff
- 40
- Scheduling Web Page
- No Scheduling Web Page Defined
- Point Of Contact
- Gordon Kohse
- Point Of Contact Email
- [email protected]
- Point Of Contact Addr1
- 138 Albany Street
- Point Of Contact Addr2
- No Point Of Contact Addr2 Defined
- Point Of Contact City
- Cambridge
- Point of Contact State
- Massachusetts
- Point Of Contact Zip
- 02139
- Point Of Contact Phone
- 617-253-4298
- Website URL
-
http://nrl.mit.edu/
- Date Of Data
- March 11, 2024
